Festo MHP2‑MS1H‑5/2‑M5 High‑Speed Poppet Solenoid Valve
Festo MHP2‑MS1H‑5/2‑M5 High‑Speed Poppet Solenoid Valve
Festo MHP2‑MS1H‑5/2‑M5 High‑Speed Poppet Solenoid Valve
Festo MHP2‑MS1H‑5/2‑M5 High‑Speed Poppet Solenoid Valve
Festo MHP2‑MS1H‑5/2‑M5 High‑Speed Poppet Solenoid Valve
Festo MHP2‑MS1H‑5/2‑M5 High‑Speed Poppet Solenoid Valve
Festo MHP2‑MS1H‑5/2‑M5 High‑Speed Poppet Solenoid Valve
Festo MHP2‑MS1H‑5/2‑M5 High‑Speed Poppet Solenoid Valve
Specifications
Model Number :
MHP2‑MS1H‑5/2‑M5
Payment Terms :
T/T
Type :
Pneumatic Cylinder
Supply Ability :
100pc
Nominal Flow Rate (DIN 1343) :
1600 l/min
Place of Origin :
Hungary
Delivery Time :
in stock
Seal Material :
NBR (nitrile rubber）
Pressure Regulation Range :
Pressure Regulation Range
MOQ :
1
Packaging Details :
carton
Mounting Position :
Any orientation
Brand Name :
Festo
Housing Width :
44 mm
Description

Festo MHP2‑MS1H‑5/2‑M5 High‑Speed Poppet Solenoid Valve

Description:

Manufacturer : Festo

Product No. : MHP2‑MS1H‑5/2‑M5

https://www.achievers-automation.com More Products


Reliable Industrial Component Sourcing for Enterprises

This industrial automation component is supplied for enterprise procurement .Made-to-order and forward delivery are supported, with pricing quoted per inquiry.

To reduce sourcing risk, each order is handled individually with support for model confirmation, condition clarification, and lead time estimation before order placement. Clear quotation terms and consistent communication are provided to help partners manage expectations and complete transactions with confidence. Additional verification or clarification is available when required, supporting professional procurement and long-term cooperation.


The FESTO MHP2‑MS1H‑5/2‑M5 is a compact direct‑acting poppet‑type solenoid valve belonging to the MHP2 series, designed for high‑speed cyclic pneumatic control in automated machinery. With 10 mm construction width and ultra‑fast switching performance up to 300 Hz, this monostable single‑solenoid valve supports standalone installation or manifold group mounting. It delivers reliable pneumatic actuation for compact automation stations, handling compressed‑air media with soft sealing and mechanical spring reset mechanism


Detail:

Item Specification Value
Part Number MHP2‑MS1H‑5/2‑M5 (Manufacturer ID: 525105)Festo
Brand FESTO
Product Category Solenoid Poppet Valve
Valve Function 5/2‑way, monostable (single solenoid, spring return)Festo
Actuation Direct electrical piloting
Construction Width 10 mm
Pneumatic Port Thread M5
Nominal Flow Rate 90 l/min (DIN 1343 standard)Festo
Operating Voltage 24 V DC
Operating Pressure -0.9 bar ~ 8 bar
Switching Time ON 1.9 ms
Switching Time OFF 1.7 ms
Max Switching Frequency 300 Hz
Operating Medium Compressed air ISO 8573‑1:2010 [7:4:4]
Ambient Temperature -5 °C ~ +40 °C
Degree of Protection IP65
Weight 70 g
Electrical Connection 2‑pin plug connector

Attribute Details
Housing Material Coated die‑cast zinc
Seal Material NBR / HNBR soft sealing
Fastener Material Galvanised steel
Reset Method Mechanical spring
Exhaust Feature Throttle‑adjustable exhaust port
Manual Override Non‑detenting push‑type
Certifications CE, UKCA, c UL us‑Recognised, RCM
Compliance RoHS, EMC directive compliant
UNSPSC Code 32151605
HS Customs Code 84812090
ECCN EAR99
Mounting Single installation or PR‑rail manifold mounting
