P&F HiC2821 Switch Amplifier Isolated Barrier
P&F HiC2821 Switch Amplifier Isolated Barrier
P&F HiC2821 Switch Amplifier Isolated Barrier
P&F HiC2821 Switch Amplifier Isolated Barrier
Specifications
Model Number :
HiC2821
Output Polarity :
DC
Switching Frequency :
≤ 10 Hz
Linearity Error :
0.1 %
Target Size :
0.3 mm
Brand Name :
P&F
Interface Type :
RS-485 , 2-wire multidrop
Payment Terms :
D/A
Construction Type :
M12
Tightening Torque :
0.6 Nm
Length :
63.5 mm
Place of Origin :
Singapore
MOQ :
1
Output Current :
4-20 mA
Description

P&F HiC2821 Switch Amplifier Isolated Barrier


Product Details:

Manufacturer : Pepperl + Fuchs

Product No. : HiC2821

https://www.achievers-automation.com More Products


Reliable Industrial Component Sourcing for Enterprises

This industrial automation component is supplied for enterprise procurement .Made-to-order and forward delivery are supported, with pricing quoted per inquiry.

To reduce sourcing risk, each order is handled individually with support for model confirmation, condition clarification, and lead time estimation before order placement. Clear quotation terms and consistent communication are provided to help partners manage expectations and complete transactions with confidence. Additional verification or clarification is available when required, supporting professional procurement and long-term cooperation.


The HiC2821 supports flexible configuration via onboard DIP switches. It can operate as a signal splitter with one input and two relay outputs. Users can set the second relay channel for duplicate signal output or dedicated fault indication. Built-in Line Fault Detection (LFD) monitors wire breakage and short-circuit faults on field wiring. This module adopts bus-powered design and directly plugs onto HiC termination boards to optimize cabinet wiring layout for process control systems.

Detail:


Parameter Specification
Model Number HiC2821
Brand Pepperl+Fuchs (P+F)
Product Type Switch Amplifier / Isolated Intrinsic Safety Barrier
Channel Count 1 Channel (Field Input)
Power Supply 19 VDC – 30 VDC, bus-powered via termination board
Max Power Dissipation ≤ 500 mW
Rated Operating Current ≤ 30 mA
Supported Input Signals NAMUR sensor (EN 60947-5-6), dry contact
Field Input Monitoring Line Fault Detection (open circuit / short circuit)
Primary Output Relay contact signal output
Secondary Output Selectable duplicate signal or fault relay output
Relay Contact Rating 50 VDC, max 0.5 A
Minimum Switching Current 2 mA @ 24 VDC
Response Delay ≤ 20 ms pick-up / ≤ 20 ms drop-off
Safety Level SIL 2 (IEC 61508)

Parameter Specification
Mounting Style Plug-in onto HiC termination board
Module Width 12.5 mm
Housing Material Flame-retardant engineering plastic
Ambient Operating Temperature -20 °C ~ +60 °C
Storage Temperature -40 °C ~ +70 °C
Relative Humidity Max. 90 %, non-condensing
Mechanical Relay Service Life 10⁶ switching cycles
Electromagnetic Compliance EN 61326-1 (industrial environments)
Hazardous Area Certifications ATEX, IECEx, UL
Approved Hazardous Zones Zone 0, Zone 1, Zone 2
Galvanic Isolation Basic insulation per EN 50178
Status Indicator Multi-color diagnostic LED
Approximate Unit Weight 95 g
