Festo DSBCG-100--ISO Standard Pneumatic Cylinder
Festo DSBCG-100--ISO Standard Pneumatic Cylinder
Festo DSBCG-100--ISO Standard Pneumatic Cylinder
Festo DSBCG-100--ISO Standard Pneumatic Cylinder
Specifications
Model Number :
DSBCG-100--
Packaging Details :
carton
Mounting Position :
Any orientation
Brand Name :
Festo
Housing Width :
44 mm
Delivery Time :
in stock
Seal Material :
NBR (nitrile rubber）
Payment Terms :
T/T
Type :
Pneumatic Cylinder
Supply Ability :
100pc
Nominal Flow Rate (DIN 1343) :
1600 l/min
Place of Origin :
China
MOQ :
1
Pressure Regulation Range :
Pressure Regulation Range
Description

Festo DSBCG-100--ISO Standard Pneumatic Cylinder


Description:

Manufacturer : Festo

Product No. : DSBCG-100--

https://www.achievers-automation.com More Products


Reliable Industrial Component Sourcing for Enterprises

This industrial automation component is supplied for enterprise procurement .Made-to-order and forward delivery are supported, with pricing quoted per inquiry.

To reduce sourcing risk, each order is handled individually with support for model confirmation, condition clarification, and lead time estimation before order placement. Clear quotation terms and consistent communication are provided to help partners manage expectations and complete transactions with confidence. Additional verification or clarification is available when required, supporting professional procurement and long-term cooperation.



The Festo DSBCG-100-- belongs to the DSBCG standards-based pneumatic cylinder series, developed based on ISO 15552 international standard. It features a robust profile barrel structure, double-acting operation, and multi-option end cushioning systems. The DSBCG-100-- model comes with 100 mm piston bore, configurable stroke lengths, and reserved sensor grooves for proximity switch installation to achieve position feedback.

Modular design supports abundant customized variants for diverse industrial linear actuation scenarios. Interchangeable dimensions guarantee convenient replacement for legacy ISO cylinders in production lines.

Detail:


Parameter Specification
Model Code DSBCG-100--
Brand Festo
Product Series DSBCG Standard Profile Cylinder
Operating Principle Double-acting
Piston Bore 100 mm
Available Stroke Range 1 mm – 2800 mm
Piston Rod Thread M20×1.5
Standard ISO 15552
Pneumatic Connection G1/2
Operating Pressure 0.4 bar ~ 12 bar (0.04 MPa ~ 1.2 MPa)
Operating Medium Compressed air ISO 8573-1:2010 [7:4:4]
Theoretical Force (6 bar Advance) 4712 N
Theoretical Force (6 bar Retract) 4418 N
Cushioning Options P, PPV, PPS


Parameter Specification
Cylinder Barrel Material Smooth anodized wrought aluminum alloy
Piston Rod Material High-alloy polished steel
Seal Material TPE-U (PU)
Ambient Temperature Range -20 °C ~ +80 °C
Mounting Position Unlimited (any installation orientation)
Position Detection Support proximity sensor installation
Max Permissible Rod Torque 3 Nm
Certification CE, RoHS, UKCA
Corrosion Resistance Class CRC 2
LABS Compatibility VDMA 24364-B1/B2-L compliant
