Phoenix Contact MINI MCR-2-UI-UI 3-Way Isolated Signal Conditioner

Specifications

Model Number :

MINI MCR-2-UI-UI

Input Voltage :

5V ± 5% (from PC USB port)

Payment Terms :

T/T

Protection Level :

IP54

Integral Indicator :

Digital indicato

Supply Ability :

1000pcs per week

Cell Constant :

0.05 cm-1, 5 cm-1

Brand Name :

Phoenix Contact

Ph Measuring System :

For FLXA402, PH202, FLXA202, FLXA21 (*2)

MOQ :

Packaging Details :

carton

Surface :

SMS01

Price :

Negotiable

Contact Input :

Two points

Certification :

HART

Place of Origin :

Connecting Cable :

KS1 KS2

Description

Phoenix Contact MINI MCR-2-UI-UI 3-Way Isolated Signal Conditioner

Product Details:

Manufacturer : Phoenix Contact

Product No. : MINI MCR-2-UI-UI

https://www.achievers-automation.com More Products

Reliable Industrial Component Sourcing for Enterprises

This industrial automation component is supplied for enterprise procurement .Made-to-order and forward delivery are supported, with pricing quoted per inquiry.

To reduce sourcing risk, each order is handled individually with support for model confirmation, condition clarification, and lead time estimation before order placement. Clear quotation terms and consistent communication are provided to help partners manage expectations and complete transactions with confidence. Additional verification or clarification is available when required, supporting professional procurement and long-term cooperation.

The Phoenix Contact MINI MCR-2-UI-UI belongs to the MINI Analog Pro signal conditioning series. This compact module delivers three-way galvanic isolation between input, output and power supply to suppress ground loop interference in analog measurement circuits.

Both input and output signal ranges can be flexibly configured through onboard DIP switches without additional software. It supports common unipolar and bipolar standard analog voltage and current signals widely used in process automation. Automatic calibration eliminates manual trimming after range switching. Built-in signal filtering improves stability in noisy industrial environments. The narrow 6.2 mm housing enables high-density installation on standard 35 mm DIN rails. Screw terminal connection provides reliable wiring for field instrumentation loops.

Detail:

Parameter	Specification
Model Number	MINI MCR-2-UI-UI
Brand	Phoenix Contact
Series	MINI Analog Pro
Product Type	3-Way Isolated Analog Signal Conditioner
Isolation Mode	Reinforced isolation, Input / Output / Power separated
Isolation Test Voltage	3 kV AC (50 Hz, 60 s)
Rated Insulation Voltage	300 V
Supply Voltage Range	9.6 VDC ~ 30 VDC
Typical Power Consumption	≤ 800 mW
Input Signal Types	Voltage / Current configurable via DIP switch
Available Input Ranges	0/4–20 mA, -20–20 mA; 0–5 V, 1–5 V, 0–10 V, -10–10 V, 0–20 V, -20–20 V
Available Output Ranges	0/4–20 mA, 0–5 V, 1–5 V, 0–10 V, -10–10 V
Max Transmission Error	≤ 0.1 % of full scale
Temperature Coefficient	≤ 0.01 % / K
Filter Options	Adjustable low-pass filter
Step Response Time (10–90 %)	≤ 8.5 ms
Current Output Max Load	≤ 600 Ω (@20 mA)
Voltage Output Min Load	≥ 10 kΩ

Parameter	Specification
Housing Width	6.2 mm
Mounting Standard	35 mm DIN rail (EN 60715)
Connection Type	Screw terminal (M3)
Suitable Conductor Cross Section	0.14 mm² ~ 2.5 mm²
Housing Material	Flame-retardant PBT plastic
Protection Class	IP20 (for cabinet installation)
Operating Ambient Temperature	-25 °C ~ +60 °C
Storage Temperature	-40 °C ~ +85 °C
Relative Humidity	5 % ~ 95 %, non-condensing
Product Net Weight	Approx. 45 g
Overvoltage Category	II
Pollution Degree	2
Certifications	CE, RoHS
Installation Orientation	Unlimited
