Specifications
Brand Name :
BM
Model Number :
IE3
Certification :
CE
Place of Origin :
China
MOQ :
10 pcs
Price :
USD38-USD680
Payment Terms :
T/T
Supply Ability :
1000pcs per day
Delivery Time :
Usually within 30 days
Packaging Details :
Cartons/Pallet
Name :
AC Induction Motor
Insulation Class :
F
Mounting Type :
B5
Voltage :
380v
Enclosure :
IP55
Power :
0.35kw-355kw
Description

0.5HP 1HP 2HP 3HP 4HP 5HP 7.5HP 10HP 15HP 20HP 25HP 30HP 40HP 50HP 60HP 74HPThree-phase Ac Asynchronous Induction Electric Motor​

IE3 SERIES THREE PHASE ELECTRIC MOTOR

Frame number: 80 ~ 355 Power: 0.55 ~ 355KW

Working system: S1

Applications: General purpose including cutting, machine, pumps, fans, conveyors, Agricultural Machinery and food machinery
Features:Good-looking appearance, High efficiency and energy saving, low noise and little vibration. F insulation class, IP54 or IP55 protection class

OPERATING CONDITIONS:
Ambient temperature: -15senti degree≤ 0≤ 40senti degree
Altitude: Not exceeding 1000 meters
Rated voltage: 380V, 220/380V, 380/660V, 400V, 415V
Rated frequency: 50Hz / 60 Hz

Output MODEL Current Speed Eff. Power factor Tst LST T MAX Noise聽
(KW) (A) (r/min) % P.F IN IN TN dB(A)
380V 50HZ 4P
0.55 IE3-80M1-4 1.4 1430 80.8 0.75 3.7 - - -
0.75 IE3-80M2-4 1.8 1430 82.5 0.75 2.3 6.6 2.3 56
1.1 IE3-90S-4 2.6 1430 84.1 0.76 2.3 6.8 2.3 59
1.5 IE3-90L-4 3.5 1430 85.3 0.77 2.3 7 2.3 59
2.2 IE3-100L1-4 4.8 1440 86.7 0.81 2.3 7.6 2.3 64
3 IE3-100L2-4 6.3 1440 87.7 0.82 2.3 7.6 2.3 64
4 IE3-112M-4 8.4 1455 88.6 0.82 2.2 7.8 2.3 65
5.5 IE3-132S-4 11.2 1465 89.6 0.83 2 7.9 2.3 71
7.5 IE3-132M-4 15 1465 90.4 0.84 2 7.5 2.3 71
11 IE3-160M-4 21.5 1470 91.4 0.85 2.2 7.7 2.3 73
15 IE3-160L-4 28.8 1470 92.1 0.86 2.2 7.8 2.3 73
18.5 IE3-180M-4 35.3 1470 92.6 0.86 2 7.8 2.3 76
22 IE3-180L-4 41.8 1470 93 0.86 2 7.8 2.3 76
30 IE3-200L-4 56.6 1475 93.6 0.86 2 7.3 2.3 76
37 IE3-225S-4 69.6 1480 93.9 0.86 2 7.4 2.3 78
45 IE3-225M-4 84.4 1480 94.2 0.86 2 7.4 2.3 78
55 IE3-250M-4 103 1485 94.6 0.86 2.2 7.4 2.3 79
75 IE3-280S-4 136 1490 95 0.88 2 6.9 2.3 80
90 IE3-280M-4 163 1490 95.2 0.88 2 6.9 2.3 80
110 IE3-315S-4 197 1490 95.4 0.89 2 7 2.2 88
132 IE3-315M-4 236 1490 95.6 0.89 2 7 2.2 88
160 IE3-315L1-4 285 1490 95.8 0.89 2 7.1 2.2 88
200 IE3-315L2-4 352 1490 96 0.9 2 7.1 2.2 88
220 IE3-315M1-4 387 1490 96 0.9 2 7.1 2.2 95
250 IE3-355M2-4 440 1490 96 0.9 2 7.1 2.2 95
280 IE3-355L1-4 492 1490 96 0.88 2 7.1 2.2 95
315 IE3-355L2-4 554 1490 96 0.88 2 7.1 2.2 95

.0.5HP 1HP 2HP 3HP 4HP 5HP 7.5HP 10HP 15HP 20HP 25HP 30HP 40HP 50HP 60HP 74HPThree-phase Ac Asynchronous Induction Electric Motor0.5HP 1HP 2HP 3HP 4HP 5HP 7.5HP 10HP 15HP 20HP 25HP 30HP 40HP 50HP 60HP 74HPThree-phase Ac Asynchronous Induction Electric Motor

0.5HP 1HP 2HP 3HP 4HP 5HP 7.5HP 10HP 15HP 20HP 25HP 30HP 40HP 50HP 60HP 74HPThree-phase Ac Asynchronous Induction Electric Motor0.5HP 1HP 2HP 3HP 4HP 5HP 7.5HP 10HP 15HP 20HP 25HP 30HP 40HP 50HP 60HP 74HPThree-phase Ac Asynchronous Induction Electric Motor

FAQ
Q: Are you Factory or Trading Company?
A: We are Factory. That has been focusing on motors and accessories for more than 20 years.

Q: What is your warranty?
A: Our warranty is One Year. Any parts damaged within warranty. We will provide new one for free and supply the solution.

Q: What kind of motor can you supply?
A: Single Phase Motor, Three Phase Motor, NEMA standard motor, Explosion Proof Motor etc.

Q: Do you offer OEM Service?
A: Yes. We offer OEM/ODM service.

Q: What is your lead Time?
A: Usually 10 days. Precise Time depend on Qty.
