RVP42-7M Single Relay Radar Motion Sensor for Industrial Door Automation
Overview
Developed by Shenzhen JUTAI COMM CO., LTD., the RVP42-7M is a state-of-the-art microwave radar sensor designed for industrial settings. Perfect for use in environments such as industrial doors, garage doors, cold storage doors, and high-traffic access points, this sensor is highly effective in detecting vehicles and pedestrians. By utilizing advanced motion detection algorithms, it filters lateral movements and ensures precise and safe operation for automated doors.

Dimensions and Build

• Material: Anodized grey aluminum and polycarbonate housing
• Dimensions (with bracket): 164mm x 111mm x 94.5mm
• Weight: 630g
• Design: Robust and compact, the sensor offers versatility for various installation needs while providing durability and reliability in industrial environments.

Installation and Wiring

• Power Supply:
  • Voltage: 12V to 36VDC
  • Current Consumption: Less than 100mA
• Cable Color Coding:
  • Black: ±12V to 36VDC
  • Red: +12V to 36VDC
• Relay Output:
  • Default: Normally Open (NO)
  • Relay 1 COM: Yellow wire
  • Relay 1 NO: Green wire
• Installation Considerations:
  • Mount on a flat surface to reduce vibrations and potential interference.
  • Ensure that no obstructions block the detection area.
  • Keep the sensor away from fluorescent lighting and metallic objects.
  • Recommended installation height: 2m to 7m for flexible mounting in various setups.

Key Specifications

Functional Settings and Adjustment

• Sensitivity Control: Customize radar sensitivity to detect different object sizes and movement speeds.
• Detection Range: Enhanced for precise pedestrian and vehicle detection in diverse environments.

Remote Control Functionality

• Powering On: Hold the START button to turn on the radar.
• Important Note: The remote control operates only within 30 minutes after the radar is powered on. After this time, restart the radar to reactivate remote control capabilities.

Target Applications
The RVP42-7M radar sensor is ideal for:

• Industrial Doors: Perfect for enhancing safety and operational efficiency in industrial plants and warehouses.
• Garage Doors: Provides accurate vehicle detection for residential and commercial garage doors.
• Cold Storage Doors: Reliable performance in cold environments, ensuring smooth operation and energy savings.
• Dock Doors: Prevents accidents and improves traffic management by distinguishing vehicles from pedestrians at loading docks.

Main Advantages

• Automatic Operation: Doors open automatically upon detection of vehicles or pedestrians, offering hands-free operation.
• Energy Efficiency: The radar only activates the door when motion is detected, reducing energy consumption.
• Safety Enhancement: It detects and differentiates pedestrians from vehicles, providing an added layer of safety in high-traffic environments.
• Adjustable Sensitivity: Tailor detection sensitivity for various settings, ensuring optimal performance in different environments.

Final Thoughts
The RVP42-7M Single Relay Radar Motion Sensor is a versatile and reliable sensor for industrial door automation. Its advanced detection capabilities, combined with energy-efficient operation and customizable features, make it the ideal solution for a wide range of industrial environments.
