Specifications
Place of Origin :
Shanghai, China
Brand Name :
AoZhi
production capacity :
100
warranty :
1 Year
dimension(l*w*h) :
880*900*1500
power(w) :
1.5
voltage :
220V, 380V, 110V
weight (kg) :
300
video outgoing-inspection :
Provided
machinery test report :
Provided
core components :
Engine, motor
washing machine :
12 kg
drum size :
630*370 mm
speed :
32-800 RPM/min
power supply voltage :
AC110/220/380 415/440/50-60Hz V
motor power :
1.5 KW
electric heating power :
4.5 KW
cold/hot water pipe diameter :
DN20
size :
880*900*1500 mm
weight :
300 kg
Description
Product Description

Product Application
1. We are professional leading original equipment manufacturer in China. Our products are not only elegant, but also durable and our price is very competitive.
2. The model, size, color and other details of our products can be customized. You can tell us your requirements and we will give you some advice and try our best to satisfy your needs.
3. If you want to cooperate with us, you can pay field visit to our factory and we can provide you with free training. True gold does not fear fire.
4. We can provide you with some free parts with our products. When our product breaks down during normal operation under warranty period, we can deliver some parts to you for free and send you videos to teach you how to repair it.


XQG-12
XQG-15
XQG-20
XQG-25
XQG-30
Washing Capacity
12 kg
15 kg
20 kg
25 kg
30 kg
Drum size
630*370 mm
670*370 mm
670*430 mm
670*530 mm
800*500 mm
Running Speed
32-800 RPM/min
700mm x 540mm
890mm x 480mm
rated voltage
AC110/220/380/415/440/50-60Hz
410mm
410mm
motor power
1.5 KW
1.5 KW
1.5 KW
2.2 KW
2.2 KW
Electric Heating power
4.5 kw
4.5 kw
4.5 kw
6 KW
6 KW
cold/hot water pipe diameter
DN20
DN20
DN20
DN20
DN20
Drainage pipe diameter
DN80
DN80
DN80
DN80
DN80
size
880*900*1500 mm
850*950*1500 mm
880*1000*1500 mm
880*1100*1500 mm
950*1100*1500 mm
Net weight
300 kg
320 kg
350 kg
400 kg
550 kg
Upgrade Your Laundry Business with XQG Series Self-Service Washers - Fast & Secure

Main Features

Commercial self-service washing machines are emerging washing equipment, such as hotel laundry, school laundry, hospital washing machinery, washing centers, foot massage sauna centers, dry cleaners and other places. They use coin
operated, card swiping, WeChat payment, Alipay payment and other payment methods. Efficient and fast washing mode is an element to attract the young generation.
★ Adopting hard connection fixation to ensure stable operation of the machine. Customized coin insertion function;

★ Large drum design, using high-quality stainless steel material to avoid damaging clothing;
★ The washing, uniform distribution, and dehydration speed can be optimized according to actual needs;
★ Built in washing box design to avoid direct contact with clothes;
★ The clothing door is equipped with a safety door lock and a control linkage device to protect the safety of operators, suitable for hotels, laundry rooms, schools, etc.

Certifications
Upgrade Your Laundry Business with XQG Series Self-Service Washers - Fast & Secure
Upgrade Your Laundry Business with XQG Series Self-Service Washers - Fast & Secure
Upgrade Your Laundry Business with XQG Series Self-Service Washers - Fast & Secure
Upgrade Your Laundry Business with XQG Series Self-Service Washers - Fast & Secure
Our Service
Upgrade Your Laundry Business with XQG Series Self-Service Washers - Fast & Secure

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

Upgrade Your Laundry Business with XQG Series Self-Service Washers - Fast & Secure

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Packing & Delivery
Upgrade Your Laundry Business with XQG Series Self-Service Washers - Fast & Secure
Packaging
Size
980 (L) * 1000 (W) * 1600 (H)
Weight
350 kg



Packaging Details
Syntheic board
Wood pallet
