2025 Hot Sale Durable Fully Automatic 20kg Washer Extractor PLC Controller Real-time Monitoring High Efficiency Washing Machine
2025 Hot Sale Durable Fully Automatic 20kg Washer Extractor PLC Controller Real-time Monitoring High Efficiency Washing Machine
2025 Hot Sale Durable Fully Automatic 20kg Washer Extractor PLC Controller Real-time Monitoring High Efficiency Washing Machine
2025 Hot Sale Durable Fully Automatic 20kg Washer Extractor PLC Controller Real-time Monitoring High Efficiency Washing Machine
2025 Hot Sale Durable Fully Automatic 20kg Washer Extractor PLC Controller Real-time Monitoring High Efficiency Washing Machine
2025 Hot Sale Durable Fully Automatic 20kg Washer Extractor PLC Controller Real-time Monitoring High Efficiency Washing Machine
2025 Hot Sale Durable Fully Automatic 20kg Washer Extractor PLC Controller Real-time Monitoring High Efficiency Washing Machine
2025 Hot Sale Durable Fully Automatic 20kg Washer Extractor PLC Controller Real-time Monitoring High Efficiency Washing Machine
2025 Hot Sale Durable Fully Automatic 20kg Washer Extractor PLC Controller Real-time Monitoring High Efficiency Washing Machine
2025 Hot Sale Durable Fully Automatic 20kg Washer Extractor PLC Controller Real-time Monitoring High Efficiency Washing Machine
2025 Hot Sale Durable Fully Automatic 20kg Washer Extractor PLC Controller Real-time Monitoring High Efficiency Washing Machine
2025 Hot Sale Durable Fully Automatic 20kg Washer Extractor PLC Controller Real-time Monitoring High Efficiency Washing Machine
2025 Hot Sale Durable Fully Automatic 20kg Washer Extractor PLC Controller Real-time Monitoring High Efficiency Washing Machine
2025 Hot Sale Durable Fully Automatic 20kg Washer Extractor PLC Controller Real-time Monitoring High Efficiency Washing Machine
Specifications
Place of Origin :
Shanghai, China
Brand Name :
AoZhi
production capacity :
100
warranty :
1 Year
dimension(l*w*h) :
1110*1150*1570
power(w) :
2.2
voltage :
380V, 220V, 110V
weight (kg) :
700
video outgoing-inspection :
Provided
machinery test report :
Provided
core components :
motor, PLC, Engine
washing capacity :
18-22 kg
Drum volume :
220 L
Drum size :
750*500 mm
running speed :
32-800 Rpm/min
Inverter power :
2.2 KW
Electric heating power :
6/9 KW
Cold/hot water pipe diameter :
DN20 mm
Drain outlet pipe diameter :
DN50 mm
size :
1110*1150*1570 mm
Description
2025 Hot Sale Durable Fully Automatic 20kg Washer Extractor PLC Controller Real-time Monitoring High Efficiency Washing Machine
Feature：
1.PLC operating system, automatic control/manual control optional, real-time monitoring and viewing of the washing process。 2.Driven by variable frequency high-speed motor to realize stepless speed change and reduce vibration 3.Adopt sports suspension design, with spring buffering and damping shock absorption function when moving 4.Soft-mount construction eliminates the need for foundation fixing。
Product Specifications
Unit
XGQ-15
XGQ-20
XGQ-25
XGQ-30
Washing weight
kg
13-16
18-22
23-25
25-30
Volume rate
L
155
220
250
280
Cylinder
￠mm
630*500
750*500
800*500
800*600
Speed
RPM/min
32-800
32-800
32-800
32-800
voltage
V
AC110/220/380/415/440/50-60Hz
Motor power
Kw
1.5
2.2
2.5
3
Inverter
Kw
1.5
2.2
3
4
Electro-thermal
Kw
6
6/9
6/9
6/9
Cold/Hot water interface
DN
20
20
20
20
Drainage interface
DN
50
50
50
50
Noise
dB
＞70
＞70
＞70
＞70
Dim
mm
1000*1100*1500
1100*1150*1570
1160*1150*1570
1300*1250*1700
Weight
Kg
600
700
750
800
2025 Hot Sale Durable Fully Automatic 20kg Washer Extractor PLC Controller Real-time Monitoring High Efficiency Washing Machine
1. PLC control system, English, Chinese or any language can be added as needed. 2. Fast 3 groups of direct access, 20 groups of optional programs in memory, which can be edited and stored according to the user's ideas. 3. The washing process is monitored in real time, and the data can be modified to suit different types of fabrics. 4. There are two modes of manual and automatic to choose from.
1. Made of high-quality stainless steel, with a service life of more than ten years; 2. Soft installation structure, can be used directly on the level ground; 3. The door is transparent glass, you can check the washing status very well; 4. Safe door handles and locks to ensure the safety of users.
2025 Hot Sale Durable Fully Automatic 20kg Washer Extractor PLC Controller Real-time Monitoring High Efficiency Washing Machine
2025 Hot Sale Durable Fully Automatic 20kg Washer Extractor PLC Controller Real-time Monitoring High Efficiency Washing Machine
1. Standard electric box in line with European standards; 2. The motor adopts the bottom suspension design, which can prevent the safety of the motor when water leaks; 3. Roller bearing, easy disassembly, easier maintenance; 4. You can choose cold water and hot water for washing.
1. The mesh hole is ￠3mm, which can better clean the fabric; 2. SUS stainless steel barrels will not rust for 100 years;
2025 Hot Sale Durable Fully Automatic 20kg Washer Extractor PLC Controller Real-time Monitoring High Efficiency Washing Machine
2025 Hot Sale Durable Fully Automatic 20kg Washer Extractor PLC Controller Real-time Monitoring High Efficiency Washing Machine
2025 Hot Sale Durable Fully Automatic 20kg Washer Extractor PLC Controller Real-time Monitoring High Efficiency Washing Machine
2025 Hot Sale Durable Fully Automatic 20kg Washer Extractor PLC Controller Real-time Monitoring High Efficiency Washing Machine
2025 Hot Sale Durable Fully Automatic 20kg Washer Extractor PLC Controller Real-time Monitoring High Efficiency Washing Machine
