QUINT-PS/24DC/24DC/20 Phoenix Contact UPS DC/DC converter 2320102
QUINT-PS/24DC/24DC/20 Phoenix Contact UPS DC/DC converter 2320102
QUINT-PS/24DC/24DC/20 Phoenix Contact UPS DC/DC converter 2320102
QUINT-PS/24DC/24DC/20 Phoenix Contact UPS DC/DC converter 2320102
Specifications
Brand Name :
Phoenix Contact
Model Number :
QUINT-PS/24DC/24DC/20
Place of Origin :
Thailand
MOQ :
1
Price :
negotiable
Payment Terms :
T/T,Western Union
Supply Ability :
500pcs/month
Delivery Time :
In stock
Packaging Details :
Phoenix Contact original package
Condition :
Phoenix Contact original brand new
Warranty :
one year
Shipping way :
DHL FedEx
Application :
automation industry
Description

Primary-switched QUINT DC/DC converter for DIN rail mounting with SFB (Selective Fuse Breaking) Technology, input: 24 V DC, output: 24 V DC/20 A

QUINT DC/DC converter with maximum functionality
DC/DC converters alter the voltage level, regenerate the voltage at the end of long cables or enable the creation of independent supply systems by means of electrical isolation.
QUINT DC/DC converters magnetically and therefore quickly trip circuit breakers with six times the nominal current, for selective and therefore cost-effective system protection. The high level of system availability is additionally ensured, thanks to preventive function monitoring, as it reports critical operating states before errors occur.

DC operation
Nominal input voltage range 24 V DC
Input voltage range 18 V DC ... 32 V DC
Extended input voltage range in operation 14 V DC ... 18 V DC (Derating)
Wide-range input no
Input voltage range DC 18 V DC ... 32 V DC
14 V DC ... 18 V DC (Consider derating during operation)
Voltage type of supply voltage DC
Inrush current < 26 A (typical)
Inrush current integral (I2t) < 11 A2s
Mains buffering time typ. 10 ms (24 V DC)
Current consumption 28 A (24 V, IBOOST)
Reverse polarity protection yes, ≤ 30 V DC
Protective circuit Transient surge protection; Varistor
Recommended breaker for input protection 40 A ... 50 A (Characteristics B, C, D, K)
Efficiency > 93 %
Output characteristic U/I
Nominal output voltage 24 V DC ±1 %
Setting range of the output voltage (USet) 18 V DC ... 29.5 V DC (> 24 V DC, constant capacity restricted)
Nominal output current (IN) 20 A (-25 °C ... 60 °C)
POWER BOOST (IBoost) 25 A (-25 °C ... 40 °C permanent, UOUT = 24 V DC )
Selective Fuse Breaking (ISFB) 120 A (12 ms)
Magnetic circuit breaker tripping B2 / B4 / B6 / B10 / B16 / C2 / C4 / C6
Derating 60 °C ... 70 °C (2.5 %/K)
Protection against overvoltage at the output (OVP) < 35 V DC
Max. capacitive load unlimited
Active current limitation approx. 29 A
Control deviation < 1 % (change in load, static 10 % ... 90 %)
< 2 % (change in load, dynamic 10 % ... 90 %)
< 0.1 % (change in input voltage ±10 %)
Residual ripple < 20 mVPP
Output power 480 W
Peak switching voltages nominal load < 10 mVPP (20 MHz)
Maximum no-load power dissipation 2.2 W
Power loss nominal load max. 39 W
Rise time < 2 ms (UOUT (10 % ... 90 %))
Connection in parallel yes, for redundancy and increased capacity
Connection in series yes
Signal: DC OK active
Output description UOUT > 0.9 x UN: High signal
Switching voltage range 18 V DC ... 24 V DC
Maximum inrush current < 20 mA (short-circuit-proof)
Signal: POWER BOOST, active
Output description IOUT < IN: High signal
Switching voltage range 18 V DC ... 24 V DC
Maximum inrush current < 20 mA (short-circuit-proof)
Signal: UIN OK, active
Output description UIN > 19.2 V: High signal
Switching voltage range 18 V DC ... 24 V DC
Maximum inrush current ≤ 20 mA (short-circuit-proof)
Signal: DC OK floating
Output description Relay
Output voltage ≤ 30 V AC/DC
Maximum inrush current ≤ 100 mA
