Specifications
Brand Name :
WEIDE
Model Number :
TSE-B-D
Certification :
CE
Place of Origin :
CHINA
MOQ :
1
Price :
80-110usd
Payment Terms :
L/C,T/T
Supply Ability :
5000/years
Delivery Time :
15days
Packaging Details :
10.00cm * 6.00cm * 12.00cm 3.5kg
Name :
AC Servo Motor
WDM4 :
High-Precision Universal Permanent Magnet 8-Pole AC Servo Motor
Feedback Units Available :
2500-line incremental encoder; 2500-line line-saving encoder; 17-bit single-turn absolute photoelectric encoder; 17-bit multi-turn absolute photoelectric encoder; 23-bit single-turn absolute photoelectric encoder; 23-bit multi-turn absolute photoelectric e
Compatible Drivers :
German B, B2, B2D, B2E, EH series drivers
Power Range :
0.1~7.5 KW
Motor Frame Sizes :
60mm, 80mm, 90mm, 110mm, 130mm, 180mm (six sizes available)
Motor Components :
Support brake, oil seal
Description
High Torque AC Servo Motor with 2500PPR Incremental Encoder and PWM Sine Wave Vector Control for Position Control
Advanced motion control solution featuring precision positioning and robust performance for industrial automation applications.
Product Specifications
Model Number: TSE-B-D Mathematical Model: Linear
Signal Type: Continuous Function: Automatic Control, Protection
Certifications: CCC, ISO: 9001, CE Condition: New
Customization: Non-Customized Material: Aluminum Alloy
Input Power: Single Phase L1, L2/Three Phase L1, L2, L3 AC220V
Temperature Range: Working: 0~40℃; Storing: -40~50℃
Technical Features
  • Control Type: PWM Sine Wave Vector Control
  • Feedback Mode: 2500PPR Incremental Encoder
  • Control Mode: Position Control
  • Digital Inputs: Servo-on, Clear, CCW Limit, CW Limit, Emergency Stop, Electronic Gear
  • Digital Outputs: Servo Ready, Alarm, Position Completed, Speed Arrival
  • Monitor Functions: Speed, Current Position, Position Deviation, Motor Torque
  • Protection Functions: Overspeed, Overvoltage, Overcurrent, Overload, Abnormal Braking
B Series Universal Servo Driver & Motor
Industrial Automation AC Servo Motor 0.1KW - 7.5KW High Torque AC Motors
  • Adaptive feedback unit: 2500ppr incremental encoder; 2500ppr wire-saving encoder
  • Advanced IPM (intelligent power module) with compact size, high over capacity and reliability
  • Optimized braking unit for frequent start and stop operations
  • User-friendly operation with trial operation, monitoring and parameter setting via 4-key interface
  • Adaptive power range: 0.1~3.8KW
Model Specifications
Industrial Automation AC Servo Motor 0.1KW - 7.5KW High Torque AC Motors
Model No. 10B 15B 20B 30B
Output Power (KW) 0.05-0.4 0.6-1.0 1.0-1.3 1.5-3.8
Rated Torque (N.m) 0.01-1.3 1.9-4 4-10 6-15
Input Power: Single Phase L1,L2/Three Phase L1,L2,L3 AC220V-15%~+10%
Temperature Range: Working: 0~40℃; Storing: -40~50℃
Humidity: Working: 40%~80% (no dew); Storing: below 93% (no dew)
IP Grade: IP20
Speed Frequency Response: >400Hz
Speed Regulation Ratio: 1:5000
Dimensions & Installation
Industrial Automation AC Servo Motor 0.1KW - 7.5KW High Torque AC Motors
Wiring Diagram (Position Control)
Industrial Automation AC Servo Motor 0.1KW - 7.5KW High Torque AC Motors
Certifications & Compliance
Industrial Automation AC Servo Motor 0.1KW - 7.5KW High Torque AC Motors Industrial Automation AC Servo Motor 0.1KW - 7.5KW High Torque AC Motors
Industry Applications
Industrial Automation AC Servo Motor 0.1KW - 7.5KW High Torque AC Motors
Packaging & Delivery
Industrial Automation AC Servo Motor 0.1KW - 7.5KW High Torque AC Motors
Transport Package: Carton
Specification: 355*305*310 mm
Origin: China
