Customized Smart VFD Low Voltage Vector Control VFD 220V - 380V
Customized Smart VFD Low Voltage Vector Control VFD 220V - 380V
Customized Smart VFD Low Voltage Vector Control VFD 220V - 380V
Customized Smart VFD Low Voltage Vector Control VFD 220V - 380V
Customized Smart VFD Low Voltage Vector Control VFD 220V - 380V
Customized Smart VFD Low Voltage Vector Control VFD 220V - 380V
Customized Smart VFD Low Voltage Vector Control VFD 220V - 380V
Customized Smart VFD Low Voltage Vector Control VFD 220V - 380V
Customized Smart VFD Low Voltage Vector Control VFD 220V - 380V
Customized Smart VFD Low Voltage Vector Control VFD 220V - 380V
Customized Smart VFD Low Voltage Vector Control VFD 220V - 380V
Customized Smart VFD Low Voltage Vector Control VFD 220V - 380V
Specifications
Input Voltage :
220V to 380V
Energy Function :
Four-quadrant Energy regeneration
Shipping Method :
DHL/FedEx/EMS/TNT
Packaging Specifications :
50ml~1000ml
Drive Type :
Frequency Inverter
Response Speed :
Rapid
Inputfrequency :
50/60 Hz
Energy Regeneration :
Four-quadrant
Protectionfeatures :
Overvoltage, undervoltage, overload, short circuit, phase loss
Humidityrange :
5% to 95% non-condensing
Application :
Pumps,fans,compresors,conveyors,Crane
Torque Control :
Direct
Controlmethod :
V/f control, Vector control, Sensorless vector control
Insulation Voltage :
800V/1600V
Output Power :
0.75KW-55KW
Model No :
N310-20P5
Brand Name :
LAEG
Model Number :
LD320-1R5G-T4B
Certification :
CE
Place of Origin :
CHINA
MOQ :
1
Price :
73 USD
Payment Terms :
L/C,T/T
Supply Ability :
5000/Months
Delivery Time :
15days
Packaging Details :
12*9*9 cm
Motor Compatibility :
PMSM Motor
Displaytype :
LCD or LED display
Name :
Smart VFD
Size :
167.5*185.8*80mm
Powerrating :
0.5 kW to 500 kW
Output Voltage :
Customizable
Power Range :
2.2KW-5000KW
Frequency Resolution :
0.01Hz
Colour :
grey
Output Phase :
3phase
Voltage :
220V,380V,400V,415V,440V,460V,480V
Accuracy :
0.5% for VF application
Description
Ld320 Smart Drive Solution Enhancing Productivity and Efficiency for Modern Manufacturing Operations
Enhancing productivity and efficiency for modern manufacturing operations with advanced vector control technology.
Product Specifications
Model Number LD320-1R5G-T4B
Working Principle Vector Control Transducer
Switch Mode PWM Control
Main Circuit Type Current
Power Supply Voltage Low Voltage Variable-Frequency Drive
Transformation Link AC-DC-AC Variable-Frequency Drive
DC Power Nature Current Variable-Frequency Drive
Function Simple Type
Brand Laeg
Protection Degree IP55/65
Voltage 380V, or Customized
Frequency 50Hz, 60Hz
Output Frequency 0.01-400 Hz
Transport Package Wooden Cases
Specification 12*9*9 cm
Trademark LAEG
Origin Anhui China
HS Code 8504400090
Production Capacity 5000/Months
Company Profile
Customized Smart VFD Low Voltage Vector Control VFD 220V - 380V
After more than 55 years of construction and development, Lu'an Jianghuai Motor has become the largest industrialized enterprise in the small, medium and large motor industry, with the most complete product series and the most perfect service network. Our main products include various high-efficiency and energy-saving low-voltage/high-voltage motors, DC motors, high-efficiency explosion-proof motors, special motors, permanent magnet motors, and other synchronous/asynchronous motors. ANHUI LAEG is the branch of Luan Jianghuai motor company, specializing in VFD production for over 20 years.
Inverter Advantages
  • Compact Size: Advanced modular design saves over 30% volume compared to same-power inverters
  • Better Excitation Performance: Automatically adjusts motor excitation current for improved efficiency and energy savings
  • Multiple Display Options: Choose between digital or LCD operation panels for enhanced parameter visibility
  • Universal Drive Capability: Operates three-phase asynchronous motors, permanent magnet synchronous motors, and servo motors
  • High Reliability: Long-life components and enhanced substrate coatings ensure durability and ROHS compliance
Detailed Product Specifications
Model AD10-4R0G-T4-B
Motor Power 4 kW / 5 HP
Rated Output Capacity 5.9 kVA
Rated Output Current 9 A
Output Frequency 0.01-400 Hz
Carrier Frequency Range 1-16 kHz
Overload Capacity 150% for 60 seconds, 200% for 3 seconds
Input Current 10.5 A
Input Voltage & Frequency 3 phase 380V, 50-60Hz
Voltage Range 315V-450V
Cooling System Forced cold air
Brake Unit In-build
Customized Smart VFD Low Voltage Vector Control VFD 220V - 380V
Technical Specifications Table
Input Voltage/Frequency Model Input Current (A) Motor Power (KW) Motor Horsepower (HP) Rated Output Capacity (KVA) Output Current (A) Output Frequency Carrier Frequency
1AC 220V 50/60Hz AD10-0R7G-S2B 8.2 0.75 1 1.5 4 0.1-400Hz 1-16kHz
AD10-1R5G-S2B 14 1.5 2 3 7
AD10-2R2G-S2B 23 2.2 3 4 9.6
3AC 380V 50/60Hz AD10-0R7G-T4B 3.4 0.75 1 1.5 2.1 0.1-400Hz 1-16kHz
AD10-1R5G-T4B 5 1.5 2 3 3.8
AD10-2R2G-T4B 5.8 2.2 3 4 5.1
AD10-4R0G-T4B 10.5 3.7 5 5.9 9
AD10-5R5G-T4B 14.6 5.5 7.5 8.9 13
AD10-7R5G-T4B 20.5 7.5 10 11 17
AD10-011G-T4B 26 11 15 17 25
Applications
Customized Smart VFD Low Voltage Vector Control VFD 220V - 380V
Factory Environment
Our motor factory scale and product line, products details
Customized Smart VFD Low Voltage Vector Control VFD 220V - 380V Customized Smart VFD Low Voltage Vector Control VFD 220V - 380V Customized Smart VFD Low Voltage Vector Control VFD 220V - 380V Customized Smart VFD Low Voltage Vector Control VFD 220V - 380V
Certifications
We have CE, ISO9001, CCC and other certifications
Customized Smart VFD Low Voltage Vector Control VFD 220V - 380V
Packaging
Customized Smart VFD Low Voltage Vector Control VFD 220V - 380V
Frequently Asked Questions
Are you a factory or trading company?
LU'AN JIANGHUAI is a factory that has been focusing on motors and accessories for more than 50 years.
What about the warranty?
We offer 12 month warranty period as the quality guarantee.
Can you do OEM?
Yes, we offer OEM services.
How about your service?
We have pre-sale service, in-sale service and after-sale service. What we pursue is long-term cooperation, so our principle is customer first.
What are your terms of delivery?
Generally we ship in FOB term, but we could offer the solution for CNF, CIF and DDP, which all based on your requirement.
What's the delivery time?
15 to 35 days after receiving your payment in advance.
