Ultra Slim Indoor LED Module Full Color P2.5-P10 Space Saving For Advertising
Ultra Slim Indoor LED Module Full Color P2.5-P10 Space Saving For Advertising
Specifications
Model Number :
ABXING indoor Led Module Series
LED Module Size :
320*160mm
MOQ :
4
Delivery Time :
15-18 Working day
IP Rate :
IP31
Service Access :
Front/Rear
Payment Terms :
T/T,Western Union
Color Temperature :
3000-10000 K(adjustable)
Warranty :
1Year
Supply Ability :
Monthly production capacity: 500000 pieces
Brightness :
500Nits-800Nits
Power Supply :
5V
Certification :
CE/FCC/CCC/EMC
Weight :
300G
Place of Origin :
China
Refresh Rate :
3840Hz
Price :
19.9-45.9
Working Temperature: :
-20 ~ +60 ℃
Brand Name :
ABXING LED
Pixel Pitch :
P2.5,P3.076,P4,P5,P6.67,P8,P10
Packaging Details :
Environmentally friendly wooden case
Life Span :
100000 Hrs
Description
Indoor LED Module ABXING Ultra Slim Design for Space Saving Indoor Advertising Screens
ABXING Indoor LED Display Modules - High Refresh Rate, Premium SMD Technology, Built to Perform
Nationstar/Kinglight/Hongsen LEDs. Advanced Driver ICs. 72-Hour Aging Test. 2-Year Warranty.
The ABXING Indoor LED Display Modules are engineered for demanding indoor applications requiring exceptional visual performance, superior color uniformity, and long-term reliability. Featuring SMD 3-in-1 full-color LED technology, premium LED chips from Nationstar, Kinglight, and Hongsen, and advanced driver ICs, these modules deliver stunning imagery for corporate lobbies, broadcasting studios, control rooms, and retail environments.
Ultra Slim Indoor LED Module Full Color P2.5-P10 Space Saving For Advertising
Key Features & Benefits
  • Premium LED Lamps - High-quality chips from Nationstar, Kinglight, and Hongsen providing high color contrast and superior color uniformity
  • Advanced Driver ICs - MBI5153, MBI5124, ICN2153, and ICN1065L ensuring high refresh rate and high gray level performance
  • 72+ Hours Aging Test - White balance aging (2 * 24 hours) and video aging (24 hours) guaranteeing no broken LEDs and maximum reliability
  • High Refresh Rate - Flicker-free viewing experience with camera-friendly performance and smooth motion
  • Exceptional Contrast & Color Uniformity - Best-in-class contrast for deep blacks and vivid colors across the entire display surface
  • Comprehensive Pixel Pitches - Available from ultra-fine P1.25 to standard P5 to meet diverse project requirements
  • Standard Module Size - 320*160mm readily available for fast delivery and reduced lead times
  • Included Accessories - Data power cables included with every module
  • International Certifications - CE, RoHS, FCC certified meeting global safety and environmental standards
  • 2-Year Warranty - Comprehensive coverage for peace of mind
Ultra Slim Indoor LED Module Full Color P2.5-P10 Space Saving For Advertising
Technical Specifications
Technology SMD 3-in-1 full-color LED
Application Indoor environments
Chip Brands Nationstar, Kinglight, Hongsen
Driver ICs MBI5153, MBI5124, ICN2153, ICN2038S
Aging Test 72+ hours (white balance + video)
Warranty 2 Years
Certifications CE, RoHS, FCC
Module Size 320*160mm (in stock)
Available Pixel Pitches
320*160mm: P1.25 | P1.5 | P1.667 | P1.86 | P2 | P2.5 | P3.076 | P4 | P5
Typical Applications
Corporate Lobbies Control Rooms Broadcasting Studios Retail Displays Conference Rooms Exhibition Centers
The ABXING Indoor LED Display Modules combine premium components, rigorous testing, and thoughtful engineering to deliver exceptional performance and reliability for any indoor application.
