P2.5-P10 Outdoor LED Display Module IP65 Waterproof LED Module For Advertising Billboards / Signage
P2.5-P10 Outdoor LED Display Module IP65 Waterproof LED Module For Advertising Billboards / Signage
Specifications
Model Number :
ABXING outdoor Led Module Series
LED Module Size :
320*160mm
MOQ :
4
Delivery Time :
15-18 Working day
IP Rate :
IP65
Service Access :
Front/Rear
Payment Terms :
T/T,Western Union
Color Temperature :
3000-10000 K(adjustable)
Warranty :
1Year
Price :
19.9-45.9
Working Temperature: :
-20 ~ +60 ℃
Supply Ability :
Monthly production capacity: 500000 pieces
Brightness :
5000Nits-8000Nits
Power Supply :
5V
Certification :
CE/FCC/CCC/EMC
Weight :
300G
Place of Origin :
China
Refresh Rate :
3840Hz
Brand Name :
ABXING LED
Pixel Pitch :
P2.5,P3.076,P4,P5,P6.67,P8,P10
Packaging Details :
Environmentally friendly wooden case
Life Span :
100000 Hrs
Description
Outdoor LED Module ABXING Waterproof Display Panel for Advertising Billboards and Signage
ABXING Outdoor LED Display Modules - High Brightness, IP65 Waterproof, Built to Last. Premium Chips. Advanced Driver IC. 72+ Hours Aging Test. 2-Year Warranty.
The ABXING Outdoor LED Display Modules are engineered for demanding outdoor applications requiring exceptional brightness, durability, and visual performance. Featuring SMD 3-in-1 encapsulation, IP65 waterproof protection, and premium LED chips from Nationstar and Kinglight, these modules deliver vivid, reliable imagery in any environment. Backed by a 2-year warranty and certified to CE, RoHS, and FCC standards, ABXING outdoor modules are the smart choice for professionals who demand the best.
P2.5-P10 Outdoor LED Display Module IP65 Waterproof LED Module For Advertising Billboards / Signage
Key Features & Benefits
  • Premium LED Chips - High-quality chips from Nationstar and Kinglight. Exceptional brightness, superior color consistency, and long-term reliability.
  • Advanced Driver ICs - MBI5153, MBI5124, ICN2153, and ICN1065L. High refresh rate and high gray level for superior visual performance. Flicker-free, broadcast-quality video.
  • 72+ Hours Aging Test - White balance aging (2 * 24 hours) and video aging (24 hours). Ensures no broken LEDs and maximum reliability. Reduces field failures.
  • IP65 Waterproof & Dustproof - Sealed construction protects against rain, snow, and dust. Reliable performance in challenging outdoor conditions.
  • Comprehensive Pixel Pitches - SMD: P2.5, P3.076, P4, P5, P6.67, P8, P10. DIP: P10, P16, P20. One module platform, multiple applications.
  • Stock Module Sizes - 320*160mm and 256*128mm readily available. Fast delivery and reduced lead times.
  • CE, RoHS, FCC Certified - Meets international safety and environmental standards. Quality you can trust.
  • 2-Year Warranty - Comprehensive coverage for peace of mind. Confidence in your investment.
P2.5-P10 Outdoor LED Display Module IP65 Waterproof LED Module For Advertising Billboards / Signage
Technical Specifications
Technology
SMD 3-in-1 encapsulation
Protection Rating
IP65 waterproof and dustproof
Chip Brands
Nationstar, Kinglight
Driver ICs
MBI5153, MBI5124, ICN2153, ICN1065L
Aging Test
72+ hours (white balance + video)
Warranty
2 Years
Certifications
CE, RoHS, FCC
P2.5-P10 Outdoor LED Display Module IP65 Waterproof LED Module For Advertising Billboards / Signage
Available Configurations
Pixel Pitches:
P2.5 P3.076 P4 P5 P6.67 P8 P10 P10 (DIP) P16 (DIP) P20 (DIP)
Standard Sizes:
320*160mm 256*128mm
Typical Applications
Billboards, stadium displays, retail signage, transportation hubs, and architectural installations.
The ABXING Outdoor LED Display Modules combine premium components, rigorous testing, and thoughtful engineering to deliver exceptional performance and reliability for professional outdoor display applications.
