IP65 Weatherproof Mobile Trailer LED Display 4500Nits-10000Nits 160° Wide Viewing Angle

Specifications

Model Number :

ABXING Mobile Trailer LED Display

Supply Ability :

Monthly production capacity: 20 pieces

Cabinet Size (mm) :

960*960,500*1000

MOQ :

Gray Grade (Bits) :

14Bits

Protection Grade :

IP65

Delivery Time :

25-35days

Refresh Frequency (Hz) :

≥3840

Payment Terms :

T/T,Western Union

Operation Power :

AC100-240V 50-60Hz

Packaging Details :

Environmentally friendly wooden case

Working Temperature (ºC) :

-20～+60

Certification :

CE/FCC/CCC/EMC

Module Size (mm) :

320*160,250*250

Place of Origin :

China

Brightness (CD/㎡) :

4500Nits-10000Nits

Brand Name :

ABXING LED

Price :

>$8860

Pixel Pitch (mm) :

P10,P8,P6.667,P5,P4.81,P3.91,P3,P2.976,P2.604

Maintenance method :

Rear/Front

Description

ABXING Mobile Trailer LED Display | All-Weather Outdoor Advertising Solution

ABXING's mobile trailer LED display delivers broadcast-quality visuals in a fully portable, rugged package. Ideal for outdoor advertising, events, and emergency broadcasts, this complete plug-and-play solution includes an integrated power system and heavy-duty trailer built for tough conditions. No permanent installation or external infrastructure is needed—just bring your message to the streets, festivals, or job sites.

IP65 Weatherproof Mobile Trailer LED Display 4500Nits-10000Nits 160° Wide Viewing Angle

Key Features

Fully Integrated & Road Legal: Each mobile LED screen trailer is a turnkey system requiring no complex assembly. Designed to meet international road transportation standards, it tows easily and sets up in under 30 minutes—perfect for fast-moving rental and advertising teams.
High Brightness & Wide Viewing Angle: With 5000-10,000 nits brightness, this outdoor LED advertising trailer remains clearly visible even in direct sunlight. A 160° wide viewing angle and multiple pixel pitch options (P2.5 to P10) ensure your content reaches more viewers.
IP65 Weatherproof & All-Weather Ready: Rated IP65, the display is fully protected against rain, dust, and moisture. Combined with robust, corrosion-resistant aluminum cabinets, this all-weather trailer LED display works reliably from -30°C to 45°C.
Flexible Power Options: Use grid power, an onboard generator, or an optional solar hybrid system. Automatic source switching ensures your mobile LED billboard trailer runs nonstop—ideal for off-grid locations or extended outdoor campaigns.
Smart Control & Multi-Screen Sync: Control your screen remotely via 4G/5G or WiFi. Synchronize multiple trailers in real time, schedule content in advance, and monitor performance from any location.
Durable & Secure Construction: A shock-absorbing mounting system protects LEDs during transit. Reinforced frames, hydraulic self-leveling, lockable compartments, and optional side wings make this one of the most secure and versatile mobile LED video trailers available.

Applications

Event & Entertainment Pros

Perfect for concerts, sports events, festivals, and public gatherings. A mobile LED display trailer brings big-screen energy to any temporary venue.

Emergency & Public Information Units

Used by governments and emergency services for crisis broadcasts, traffic alerts, and public safety announcements.

Advertising & Retail Brands

Launch products, run mobile ad campaigns, or promote retail sales with a mobile advertising LED trailer that travels to high-footfall areas.

Construction & Corporate Sites

Display safety messages, training content, or corporate communications across multiple locations.

IP65 Weatherproof Mobile Trailer LED Display 4500Nits-10000Nits 160° Wide Viewing Angle

Why Choose ABXING?

Save on venue costs and reduce labor with fast setup
Generate new revenue streams through mobile advertising and rentals
No special towing license required for most standard models
CE, UL, and RoHS certified; backed by a 3-year warranty and 24/7 support

Customization Options

Add audio systems, live camera feeds, curved screens, custom branding wraps, or solar power. ABXING works with you to build a custom mobile LED trailer that fits your exact needs.

IP65 Weatherproof Mobile Trailer LED Display 4500Nits-10000Nits 160° Wide Viewing Angle

Get Started

ABXING's mobile trailer LED displays redefine outdoor visual communication. Whether you're a rental company, brand advertiser, or event organizer, our trailers help you engage audiences where fixed screens can't go. Contact our team today for a customized proposal—let's build your mobile visual solution together.

Outdoor ABXING Mobile Trailer LED Display 960*960mm Series Technical Specifications

Pixel Pitch (mm)	P2.5	P3.076	P4	P5	P6.667	P8	P10
Model	ABXINGMT 2.5-16SO	ABXINGMT 3.076-13SO	ABXINGMT 4-10SO	ABXINGMT 5-8SO	ABXINGMT 6.667-6SO	ABXINGMT 8-5SO	ABXINGMT 10-2SO
Pixel Configuration	SMD1415	SMD1415	SMD1921	SMD1921	SMD3535	SMD3535	SMD3535
Density (Pixels/㎡)	147,928	112,896	65,536	65,536	43,264	65,536	10,000
Module Resolution (Pixel)	128*64	104*52	80*40	64*32	144*72	40*20	32*16
Module Size (mm)	320*160	320*160	320*160	320*160	320*160	320*160	320*160
Driving Mode (Duty)	1/16	1/13	1/10	1/8	1/6	1/5	1/2
Cabinet Size (mm)	960*960	960*960	960*960	960*960	960*960	960*960	960*960
Cabinet Weight (KG)	32	32	32	32	32	32	32
Brightness (CD/㎡)	5000-5500	5000-5500	5000-5500	5000-5500	5000-5500	5000-5500	6500-10000
Viewing Angle (°)	140	140	140	140	140	140	140
Gray Grade (Bits)	14	14	14	14	14	14	14
Operation Power	AC100-240V 50-60Hz	AC100-240V 50-60Hz	AC100-240V 50-60Hz	AC100-240V 50-60Hz	AC100-240V 50-60Hz	AC100-240V 50-60Hz	AC100-240V 50-60Hz
Max. Power Consumption (W/㎡)	720	720	720	720	720	720	720
Avg. Power Consumption (W/㎡)	240	240	240	240	240	240	240
Frame Frequency (Hz)	≥60	≥60	≥60	≥60	≥60	≥60	≥60
Refresh Frequency (Hz)	≥3840	≥3840	≥3840	≥3840	≥3840	≥3840	≥3840
Working Temperature (ºC)	-20～+60	-20～+60	-20～+60	-20～+60	-20～+60	-20～+60	-20～+60
Protection Grade	IP65	IP65	IP65	IP65	IP65	IP65	IP65
Maintenance method	Rear	Rear	Rear/Front	Rear/Front	Rear/Front	Rear/Front	Rear/Front

Outdoor ABXING Mobile Trailer LED Display 500*1000mm Series Technical Specifications

Pixel Pitch (mm)	P2.6	P2.97	P3.91	P3.91	P4.81
Model	ABXINGMT 2.6-24SO	ABXINGMT 2.97-21SO	ABXINGMT 3.91-16SO	ABXINGMT 3.91-8SO	ABXINGMT 4.81-13SO
Pixel Configuration	SMD1415	SMD1415	SMD1921	SMD1921	SMD1921
Density (Pixels/㎡)	147,928	112,896	65,536	65,536	43,264
Module Resolution (Pixel)	96*96	84*84	64*64	64*64	52*52
Module Size (mm)	250*250	250*250	250*250	250*250	250*250
Driving Mode (Duty)	1/24	1/21	1/16	1/8	1/13
Cabinet Size (mm)	500*1000	500*1000	500*1000	500*1000	500*1000
Cabinet Weight (KG)	13	13	13	13	13
Brightness (CD/㎡)	4500	4500	4500	5500	4500
Viewing Angle (°)	140	140	140	140	140
Gray Grade (Bits)	14	14	14	14	14
Operation Power	AC100-240V 50-60Hz	AC100-240V 50-60Hz	AC100-240V 50-60Hz	AC100-240V 50-60Hz	AC100-240V 50-60Hz
Max. Power Consumption (W/㎡)	720	720	720	720	720
Avg. Power Consumption (W/㎡)	240	240	240	240	240
Frame Frequency (Hz)	≥60	≥60	≥60	≥60	≥60
Refresh Frequency (Hz)	≥3840	≥3840	≥3840	≥3840	≥3840
Working Temperature (ºC)	-20～+60	-20～+60	-20～+60	-20～+60	-20～+60
Protection Grade	IP65(front), IP54(rear)	IP65(front), IP54(rear)	IP65(front), IP54(rear)	IP65(front), IP54(rear)	IP65(front), IP54(rear)
Maintenance method	Rear/Front	Rear/Front	Rear/Front	Rear/Front	Rear/Front
