3603E Triconex Digital Output Module TMR Architecture
3603E Triconex Digital Output Module TMR Architecture
Specifications
Brand Name :
Invensys Triconex
Model Number :
3603E
Certification :
COC
Place of Origin :
USA
MOQ :
1 Piece
Price :
inquiry
Payment Terms :
T/T
Supply Ability :
10 Piece per a day
Delivery Time :
5-8 work days
Packaging Details :
original
Name :
3603E Invensys Triconex Digital Output Modules
Model :
3603E
Package :
STANDARD
Warranty :
12 months
Gross Weight :
2.2 lbs / 35.2 oz / 1kg
Packing Size :
7" x 7" x 4" (18 cm x 18 cm x 10 cm)
Lead time :
1~3 Days
Quality :
100%Brand
Product name :
Digital Output Modules
Stock :
Available
Description

3603E Invensys Triconex Digital Output Modules

Product Details:

Brand Name Invensys Triconex
Model 3603E
Catalog TMR architecture
Origin United States (USA)
Dimension 16*16*12cm
Weight 1kg
HS Code 8537101190
Payment T/T
Sales Price $2000
Warranty 12 months
Lead time 3-5 work days


Description:

A TMR digital output (DO) module receives output signals from the main processors on each of three channels.

Each set of three signals is then voted by special quadruplicated output circuitry on the module. The circuitry produces one voted output signal and passes it to the field termination. The quadruplicated voter circuitry provides multiple redundancy for all critical signal paths, guaranteeing safety and maximum availability.

Each TMR digital output module has a voltage-loopback circuit which verifies the operation of each output switch independently of the presence of a load and determines whether latent faults exist. Failure of the detected field voltage to match the commanded state of the output point activates the LOAD/FUSE alarm indicator.

In addition, ongoing diagnostics are performed on each channel and circuit of a TMR digital output module.

Failure of any diagnostic on any channel activates the Fault indicator, which in turn activates the chassis alarm signal. The Fault indicator merely indicates a channel fault, not a module failure. The module is guaranteed to operate properly in the presence of a single fault and may continue to
operate properly with certain kinds of multiple faults.
