200V-400V Progressive Cavity Pump For Conveying High Viscosity Fluids / High Solid Content Slurries
200V-400V Progressive Cavity Pump For Conveying High Viscosity Fluids / High Solid Content Slurries
Specifications
Brand Name :
AA SS
Model Number :
CXG
Place of Origin :
China
MOQ :
1 set
Price :
$3000-$8000
Payment Terms :
L/C,T/T
Supply Ability :
1-20 sets/month
Delivery Time :
10-30 working days
Name :
Progressive Cavity Pump
Flow Range :
0.1 - 400 m³/h (wide range of models available)
Operating Pressure :
Up to 4.8 MPa (48 bar)
Operating Temperature :
-10 ~ 150℃
Inlet/Outlet Connection :
Flange, threaded or union connection, standard or customizable.
Seal Type :
Gland packing seal, single/double mechanical seal, cartridge seal optional.
Input power :
200-400V 50/60Hz
Description

Progressive Cavity Pump: Applied in conveying high-viscosity fluids, high-solid-content slurries, dewatered dry materials, and fluid/gas/solid mixtures

The progressive cavity pump is specially designed for the efficient, stable and low-shear conveyance of high-viscosity fluids, high-solid-content slurries, dewatered dry materials, and fluid/gas/solid mixtures. Its unique rotor-stator meshing working principle endows it with incomparable advantages over centrifugal pumps and conventional reciprocating pumps in handling complex media, making it a reliable choice for processing challenging fluids in industries such as food, chemical engineering, environmental protection, mining, and oil and gas.

Operating Characteristics

Wide application range, capable of conveying all flowable and even non-flowable materials.

Bi-directional rotation and bi-directional conveyance available.

Stable flow and pressure with no pulsation.

Flow rate is proportional to rotational speed, suitable for metering and dosing applications.

Low operating noise and high efficiency.

Application Fields

Energy and environmental engineering, papermaking industry, petroleum industry, chemical engineering, mineral engineering, food industry

200V-400V Progressive Cavity Pump For Conveying High Viscosity Fluids / High Solid Content Slurries

200V-400V Progressive Cavity Pump For Conveying High Viscosity Fluids / High Solid Content Slurries

200V-400V Progressive Cavity Pump For Conveying High Viscosity Fluids / High Solid Content Slurries

Technical Specifications

Working Principle

A single-headed metal rotor performs planetary rotation inside a double-headed helical elastomer stator, forming sealed chambers for material conveyance.

Flow Range

0.1 - 400 m³/h (wide range of models available)

Operating Pressure

Up to 4.8 MPa (48 bar)

Operating Temperature

-10 ~ 150℃

Solid Particle Passing Capacity

Maximum allowable particle diameter is up to approximately 80% of the rotor eccentricity (varies by specific model)

Inlet/Outlet Connection

Flange, threaded or union connection, standard or customizable.

Seal Type

Gland packing seal, single/double mechanical seal, cartridge seal optional.

Common Types

Horizontal type, vertical type, feeding type, bridge-breaking type, shaftless screw type, sanitary food grade type, short type, micro-metering type.

Main Certifications

CE, FDA (food-grade material optional), 3-A Sanitary Standard (optional)
