Aluminum Reflector Parabolic Dish 5G Communication Antenna Dia 900mm 698-3800MHz
Aluminum Reflector Parabolic Dish 5G Communication Antenna Dia 900mm 698-3800MHz
Aluminum Reflector Parabolic Dish 5G Communication Antenna Dia 900mm 698-3800MHz
Aluminum Reflector Parabolic Dish 5G Communication Antenna Dia 900mm 698-3800MHz
Aluminum Reflector Parabolic Dish 5G Communication Antenna Dia 900mm 698-3800MHz
Aluminum Reflector Parabolic Dish 5G Communication Antenna Dia 900mm 698-3800MHz
Aluminum Reflector Parabolic Dish 5G Communication Antenna Dia 900mm 698-3800MHz
Aluminum Reflector Parabolic Dish 5G Communication Antenna Dia 900mm 698-3800MHz
Aluminum Reflector Parabolic Dish 5G Communication Antenna Dia 900mm 698-3800MHz
Aluminum Reflector Parabolic Dish 5G Communication Antenna Dia 900mm 698-3800MHz
Aluminum Reflector Parabolic Dish 5G Communication Antenna Dia 900mm 698-3800MHz
Aluminum Reflector Parabolic Dish 5G Communication Antenna Dia 900mm 698-3800MHz
Specifications
Brand Name :
XJS
Model Number :
TDD-0638-30HV
Certification :
ROHS CE
Place of Origin :
Guangdong, China
MOQ :
20
Price :
USD 79-95
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
50000+PCS+month
Freq. Range :
698-3800 MHz
Gain: :
30dBi
Polarization :
Horizontal+Vertical
VSWR :
≤1.8
Impedance :
50Ω
Connector :
N-female
Dimensions :
Ф900mm
Application :
5G Devices
Material :
Aluminum
Color :
Grey
Keywords :
5G parabolic dish antenna
Description

Ultra Performance 698-3800MHz 30dBi 5G Communication Antenna Dia 900mm Aluminum Reflector Parabolic Dish Antenna

TDD-0638-30HV is a ultra performance wideband dual polarized solid dish antenna with ultra electrical performance and mechanical stability, the parabolic dish antenna can be used in a wide variety of GSM 698-960MHz, 4G LTE 1710-2700MHz and 5G 3300-3800MHz wireless applications.

Applications

  • 698-960MHz GSM wireless applications
  • 1710-2700MHz 4G LTE wireless applications
  • 3300-3800MHz
  • Long-range applications
  • Point-to-point
  • Backhaul/client antenna

Features

  • Dual polarity feed
  • Aluminum reflector dish
  • UV stable light gray polymer finish
  • All weather operation
  • Includes tilt and swivel mast mount kit

Electrical Specifications

Frequency Range 698-3800 MHz
Gain (dBi) 30 dBi
Horizontal Beamwidth 3.5°
Vertical Beamwidth 3.5°
VSWR <1.8
Polarization Horizontal+Vertical
F/B Ratio ≥38dB
Impedance 50Ω

Mechanical Specifications

Connector 2*N-female
Dimensions Φ900mm
Weight (Kg) 13kg
Lightning Protection Dc Ground
Rated Wind Speed 126/ms
Mounting Type Pole Mount
Suitable pole diameter Ф30-80mm

Details

Aluminum Reflector Parabolic Dish 5G Communication Antenna Dia 900mm 698-3800MHz

Aluminum Reflector Parabolic Dish 5G Communication Antenna Dia 900mm 698-3800MHzAluminum Reflector Parabolic Dish 5G Communication Antenna Dia 900mm 698-3800MHz

Aluminum Reflector Parabolic Dish 5G Communication Antenna Dia 900mm 698-3800MHz

Package Included

Aluminum Reflector Parabolic Dish 5G Communication Antenna Dia 900mm 698-3800MHz

Packing

Packing Details

Aluminum Reflector Parabolic Dish 5G Communication Antenna Dia 900mm 698-3800MHz
