Cold storage vehicle body panel processing center for motorhome and refrigerated truck bodies
Cold storage vehicle body panel processing center for motorhome and refrigerated truck bodies
Cold storage vehicle body panel processing center for motorhome and refrigerated truck bodies
Cold storage vehicle body panel processing center for motorhome and refrigerated truck bodies
Cold storage vehicle body panel processing center for motorhome and refrigerated truck bodies
Cold storage vehicle body panel processing center for motorhome and refrigerated truck bodies
Cold storage vehicle body panel processing center for motorhome and refrigerated truck bodies
Cold storage vehicle body panel processing center for motorhome and refrigerated truck bodies
Specifications
Brand Name :
SUBA
Model Number :
SUBA-30100
Certification :
CE
Place of Origin :
Qingdao, China
MOQ :
1
Price :
communication
Payment Terms :
,T/T,L/C
Supply Ability :
100set
Delivery Time :
5-8 work days
Packaging Details :
Wooden box packaging
Workpiece Size :
Large
Axis :
4
Size :
3000*10000*200mm
Control System :
CNC
Accuracy :
High
Materials processed :
Composite panels, RV cabin panels, refrigerated vehicle cabin panels, extruded panels, wood panels, and aluminum panels
Description

Cold storage vehicle body panel processing center for motorhome and refrigerated truck bodies

Product description:

The large panel material processing center is an intelligent CNC processing device specially designed by SpeedMaster according to the processing needs of many customers.
The workbench is equipped with a vacuum suction tabletop, the tabletop is made of phenolic resin board, which ensures the flatness and hardness of the tabletop, and is more convenient for the board.
Fixed. There is a layer of steel plate on the lower bed to ensure the flexibility of the workbench and prevent it from deforming over time. The vacuum suction workbench uses high
Efficient grid vacuum layout, so that any part of the workbench can quickly adsorb the workpiece. Large-format machining center suitable

Applicable industries:
It is used for aluminum plate, glass fiber, plastic, insulating materials, composite materials, sawing, engraving, drilling, etc. It is suitable for aerospace, rail
Automation equipment aluminum parts for transportation, vehicle interior, yachts, ships, special vehicles (refrigerated vehicles, motorhomes, modified vehicles, vaccine vehicles, etc.)
It can also be used in the intelligent production of composite materials in the fields of anti-corrosion equipment, military equipment, medical industry, instrumentation, and new energy.



Name

Cold storage vehicle body panel processing center for motorhome and refrigerated truck bodies

Effectiveworkbench size

3000*10000*200mm(Effective workbench size)

Can be customized

Z-axis travel

200mm

Workbench surface

Vacuum suction with T-groove table (suction and clamping dual-use), can be zoned according to the size of the processed board.

Spindle motor

7.5KW pneumatic tool change spindle, suitable for heavy cutting.

magazine

8 disk tool magazine (automatic tool change in program)

Spindle speed

0-12000 rpm/min

Saw motor

Five-axis control rotary saw(7.5KW)


Transmission system

The Z-axis is driven by a screw, while the X/Y axes are driven by rack and pinion

Control system

High-End Machining Center Dedicated System

Processing speed

8m/min to 45m/min (processing speed is determined based on the tools and materials used by the customer)

Distribution Cabinet

Follow-up distribution cabinet, convenient for workers to operate.

oftware

Precision Engraving/WenTai/UG/TYPE3/MASTERCAM and other internationally G-code

Working voltage

Produce according to the voltage of the customer's location.
