Proface PFXGP4301TADW high-performance 5.7-inch HMI:

The Pro-face PFXGP4301TADW is a high-performance 5.7-inch touchscreen Human-Machine Interface (HMI) from the GP4000 series, designed for industrial automation control systems. It features advanced TFT color LCD technology with 65,536 colors, providing clear and vibrant visuals even in harsh environments. The device supports SD card storage and high-speed USB 2.0 interfaces for seamless program transfer and external device connectivity.

Equipped with dual serial ports (RS-232C and RS-422/485) and a 10/100 Base-T Ethernet interface, this HMI ensures robust communication with industrial equipment and systems. Its resistive touch panel offers precise input with a resolution of 1,024×1,024 and a lifespan exceeding 1 million operations. The built-in rechargeable lithium battery safeguards program data during power outages, while IP65-rated protection guarantees durability in demanding conditions.

Technical Specifications:

Display: 5.7-inch TFT color LCD, QVGA resolution (320×240 pixels), 65,536 colors (non-blink), 16,384 colors (blink).

Touch Panel: Resistive analog type, 1,024×1,024 resolution, >1 million operations lifespan.

Communication:

COM1: RS-232C (2,400bps–115.2kbps).

COM2: RS-422/485 (2,400bps–115.2kbps, 187.5kbps MPI).

Ethernet: 10BASE-T/100BASE-TX (RJ-45).

USB: Type-A (2.0) ×1, Mini-B (2.0) ×1.

Memory:

Program Area: 132KB FLASH EPROM.

Backup: 128KB SRAM (lithium battery-backed).

Internal: 8MB FLASH EPROM.

Power: DC 24V (19.2–28.8V), 10.5W max consumption.

Environment:

Operating: 0°C to 50°C, 10–90% RH (non-condensing).

Storage: -20°C to 60°C, 10–90% RH (non-condensing).

Protection: IP65 (front panel), vibration/shock-resistant (IEC/EN61131-2).

Physical:

Dimensions: 169.5mm (W) × 137mm (H) × 59.5mm (D).

Weight: <0.8kg.

Packing & Delivery:

1)100% brand New and Original Factory Seal!

2)Warranty: 1 year

3)Package: Original packing with cartons.

4)Delivery time: Shipped in 3-7 days after payment

5) All the goods will be tested before shipment.
