SIEMENS 3RT6016-1BB41 Contactor DC 24 V AC3 4 KW 400 V AUX Contacts:


Contactor DC 24 V AC3 4 kW 400 V AUX contacts: 1 NO 3-pole, size S00 screw terminal.

The Siemens 3RT6016-1BB41 is a 3-pole contactor (DC 24V coil) designed for controlling motors and power circuits in industrial environments. Part of the SIRIUS 3RT6/3RT5 series, it offers a compact design, robust performance, and reliability for applications up to 4 kW (400 V AC-3). This model includes 1 normally open (NO) auxiliary contact and screw terminals for secure connections.



Technical Specifications:

Rated Operational Current (Ie): 9 A (AC-3, 400 V)

Control Voltage: 24 V DC

Auxiliary Contacts: 1 NO

Mounting: DIN rail or screw mounting

Rated Insulation Voltage (Ui): 690 V

Rated Impulse Withstand Voltage (Uimp): 6 kV

Mechanical Life: Up to 30 million operations

Electrical Life: Up to 1 million operations

Connection Type: Screw terminals

Dimensions (L x W x H): 61.5 mm x 78 mm x 50 mm

Weight: Approx. 0.28 kg

Operating Temperature: -25°C to +60°C

Storage Temperature: -55°C to +80°C

Approvals: IEC 60947, EN 60947, CCC, CE, UL, CSA

Protection Class: IP20 (front)
