20mm Bore Diameter SMC CD85N20-40-B Air Cylinder Double Acting Single Rod Cylinder
20mm Bore Diameter SMC CD85N20-40-B Air Cylinder Double Acting Single Rod Cylinder
Specifications
Brand Name :
SMC
Model Number :
CD85N20-40-B
Place of Origin :
JP
MOQ :
1
Price :
$99
Payment Terms :
T/T
Supply Ability :
5000
Delivery Time :
In stock/1-3days
Packaging Details :
New sealed
Description

CD85N20-40-B C85 Series Air Cylinder

The CD85N20-40-B is a standard double-acting air cylinder from the C85 series, designed for reliable and efficient performance in various industrial automation applications. It features a 20mm bore diameter and a 40mm stroke length, providing a balance between force output and speed. The cylinder is equipped with a built-in magnet, making it compatible with magnetic switches and sensors for precise position feedback. It also includes a standard rubber bumper for cushioning, ensuring smooth and quiet operation at the end of the stroke.
The CD85N20-40-B operates within a pressure range of 0.05 to 1.0 MPa and can handle an absolute maximum pressure of 1.5 MPa. It is designed to work in environments with temperatures ranging from -10°C to +60°C. The cylinder has a basic integrated clevis head cover and supports band mounting, offering flexibility in installation. With a weight of 183 grams and dimensions of 28mm in diameter and 166mm in length, it is a compact and durable solution for pneumatic systems.
Technical specifcations for CD85N20-40-B
Series : C85
Bore Diameter : 20 mm
Stroke Length : 40 mm
Rod Operation Method : Single Rod
Cushion Type : Rubber bumper (standard)
Head Cover Type : Basic (integrated clevis type)
Operating Pressure : 0.05 to 1.0 MPa
Built-in Features : Magnet
Support Bracket : None
Auto Switches : Without auto switch
Mounting Type : Band mounting
Operating Temperature : -10°C to 60°C
