A Versatile Package for a Wide Range of Color Applications
The many options within the product family give operations of all sizes the ability to build in a stable measurement system that delivers repeatable performance and increased product yield. This makes the Ci6x Series a reliable solution for a wide range of industries and applications:

Commercial Coatings. The need to meet specific color codes and regulations requires repeatable color measurement. The Ci6x Series provides the consistency demanded to ensure batch-to-batch color conformity.

Plastics. Batch consistency—from raw material through finished product—often varies depending on material supplier and process conditions. The Ci6x Series can monitor the color impact of shifts in process variables, while X-Rite application software storing color data that can be shared among the supply network to ensure color accuracy.

Automotive. Whether OEM interior, aftermarket parts, or second- and third-tier supplier components, color accuracy is an absolute must. The Ci6x system allows manufacturers at every level to achieve consistent readings. The ability to simultaneously measure SCI/SCE further enhances the quality control process.

Textiles. While materials and fabrics may appear similar at first glance, those that contain optical brightening agents (OBA) may result in a much different look under varied lighting conditions. Available calibrated UV enhanced illumination controls the UVisible balance, enabling long-term, consistent measurement of optically bright samples.

Home Furnishings. Different materials—wood, paint, plastic, metal, fabric—and a wide variety of colors, make repeatable color conformance critical. The Ci6x family is able to read a wide range of materials and provide a benchmark measurement that can be used at each step of the production or assembly process.

Short Term Repeatability - White	0.04 ΔE*ab on white ceramic
Measurement Geometry	d/8°
Inter-Instrument Agreement	0.13 ΔE*ab avg.
Illumination Spot Size	20mm or 14mm and 6.5mm
Lamp Life	Approx. 500,000 measurements
Light Source	Gas-filled tungsten lamp + UV LEDs*
Measurement Cycle Time	≈ 2 seconds
Measurement Spot	14mm or 8mm and 4mm
Measurement Time	≈ 2 seconds
Photometric Range	0 to 200%
Photometric Resolution	0.01%
Spectral Analyzer	Blue-enhanced silicon photodiodes
Spectral Interval	10nm
Spectral Range	400nm-700nm
Spectral Reporting	10nm
Color Differences	[√/X], Δecmc, Δlab, ΔE00, Δreflectance, ΔE94, ΔXYZ, ΔL*a*b*, ΔYxy, , ΔL*C*h°, ΔL*u*v*, Verbal Difference
Color Spaces	Lab, L*a*b*, Reflectance, L*C*h°, Munsell Notation, XYZ, Yxy, L*u*v*
Illuminants	A, C, D50, D65, F2, F7, F11 & F12
Observers	2° & 10°
Standard Indices	[√/X], YI1925, WI Taube, ΔWI73, Reflectance, WI98, MI, Δreflectance, ΔWI Berger, WI73, MI6172, ΔYI98, ΔWI Hunter, Gray Scale, WI Berger, Gloss, ΔYI73, ΔWI Stensby, YI98, WI Hunter, ΔYI1925, ΔWI Taube, YI73, WI Stensby, ΔWI98, Averging, 555 Shade Sort
Reflectance Aperture(s)	1 or dual
Humidity	5% to 85%, non-condensing
Operating Temperature Range	50° to 104°F (10° to 40°C)
Storage Temperature Range	'-4° to 122°F (-20° to 50°C)
Dimensions (length, width, height)	21.3 cm 9.1 cm 10.9 cm
Weight	1.06 kg
Package Dimensions (length, width, height)	51cm, 20cm, 41cm
Shipped Weight	'7kg
Communication Interface	USB 2.0, Bluetooth*
Import/Export Format	CSV
Instrument Display	Backlit Color Graphic LCD
Languages Supported	English, German, French, Spanish, Italian, Portuguese, Chinese Simplified, Chinese Traditional, Korean, and Japanese
Software Development Kit	XDS4
Battery	Li-ion
Battery Life	1000 measurements (non-UV) @ 10 sec intervals
Voltage	100-240VAC 50/60Hz, 12VDC @ 2.5A
Sample/Measurement	4000
Standards	1000
Calibration	White, Zero, UV*
Embedded NetProfiler Support	Yes
NetProfiler Support	Embedded
PantoneLIVE Support	Via software
Pass / Fail	Yes
Sample Preview	Targeting window
Transform Support	Embedded
Warranty	12 months
What's Included?	Instrument with white calibration standard, black trap, green standard, manual(CD), AC adapter, USB cable, carry case, UV cal standard*
