Specifications
Brand Name :
ZhongTeng
Model Number :
ZT--010
Place of Origin :
China
Certification :
ISO9001
MOQ :
100M2
Price :
25-89/M2
Packaging Details :
Pallets or Wooden Box
Delivery Time :
10-20Days
Payment Terms :
TT Or LC
Supply Ability :
1300/M2
Product Name :
HexMesh Refractory
Color :
Silver
Width :
0.96m
Size :
Customized
Sample :
Sample Availible
Technique  :
Bending, Cut
Thickness :
2mm,1.9mm.2.5mm
Material :
Low-Carbon Steel Or Stainless Steel304, 306.316...
Description

Product Description:

Hex Mesh, or hexagonal grid metal, is a type of refractory material that is commonly utilized in various industrial applications, including furnaces, reactors, ducts, and flues. One of its primary functions is to provide long-term protection for armor applications on industrial floors.

Hex Mesh is typically made from several different materials, including General Carbon Steel, A3, OCr13, 1Cr13, 0Cr18Ni9, 1Cr18Ni9Ti, Cr25Ni20, SUS304, SUS316, and so on. These materials are chosen for their high resistance to heat and corrosion, which makes them ideal for use in harsh industrial environments.

Hex Grid and Flex Metal Refractory Lining Features

1.Substantial insulation performances, lining tight uniform density, small energy consumption

2.High-intensity, low high-temperature liquid metal slag, and anti-erosion ability, alloying elements on the high yield

3.High sintering speed and good corrosion resistance, spalling resistance, when the shutdown of smaller crack, high crack healing ability

Material A3/Q235,SS304,310S,1Cr18Ni9Ti,0Cr13,Q345…
Gauge 1.0mm / 1.2mm / 1.5mm / 1.8mm /2.0mm / 2.5mm / 3.0mm
Height 10mm,15mm,20mm,25mm,30mm...
Aperture 50mm
Panel size 0.96m-1.0m(according to the raw material size)
Note Customers/other requirement is available for us

Applications:

Features of Hexmesh
  • Exceptional flexibility
  • High strength
  • Erosion resistance
  • Ideal for refractory linings in various high-temperature applications
  • Provides long-term protection in industrial floors with severe impact and rolling loads
  • Conforms to almost any shape or configuration
  • Perfect for reinforcing linings, floors, and any cement structures needing added support

Packing and Shipping:

Product Packaging:

  • Hexmesh Refractory is packaged in strong, durable containers to ensure safe transport and storage.
  • The containers are labeled clearly with the product name, quantity, and safety information.
  • Each container contains a product manual with instructions for use and handling.

Shipping Information:

  • Hexmesh Refractory can be shipped globally to any location.
  • We offer a variety of shipping options, including standard and express delivery.
  • Shipping costs and delivery times may vary based on the destination and shipping option selected.
  • Customers will receive a tracking number to monitor the shipment status.
  • Please inspect the product upon delivery and report any damage or issues immediately.

FAQ:

Here are the frequently asked questions about the ZhongTeng ZT-010 Hexmesh Refractory product:

Q: What is ZhongTeng ZT-010 Hexmesh Refractory?

A: ZhongTeng ZT-010 Hexmesh Refractory is a type of refractory material made of interlocking hexagonal stainless steel mesh, designed to provide excellent insulation and stability for high-temperature applications.

Q: Where is ZhongTeng ZT-010 Hexmesh Refractory made?

A: ZhongTeng ZT-010 Hexmesh Refractory is made in China.

Q: Is ZhongTeng ZT-010 Hexmesh Refractory certified?

A: Yes, ZhongTeng ZT-010 Hexmesh Refractory is certified with ISO9001, ensuring that it meets international quality standards.

Q: What is the minimum order quantity for ZhongTeng ZT-010 Hexmesh Refractory?

A: The minimum order quantity for ZhongTeng ZT-010 Hexmesh Refractory is 100 square meters.

Q: What is the price of ZhongTeng ZT-010 Hexmesh Refractory?

A: The price of ZhongTeng ZT-010 Hexmesh Refractory ranges from $25 to $89 per square meter.

Q: What are the packaging details for ZhongTeng ZT-010 Hexmesh Refractory?

A: ZhongTeng ZT-010 Hexmesh Refractory is packaged on pallets or wooden boxes to ensure safe and secure transport.

Q: What is the delivery time for ZhongTeng ZT-010 Hexmesh Refractory?

A: The delivery time for ZhongTeng ZT-010 Hexmesh Refractory is typically 10-20 days after order confirmation.

Q: What are the payment terms for ZhongTeng ZT-010 Hexmesh Refractory?

A: The payment terms for ZhongTeng ZT-010 Hexmesh Refractory are either TT (Telegraphic Transfer) or LC (Letter of Credit).

Q: What is the supply ability of ZhongTeng ZT-010 Hexmesh Refractory?

A: The supply ability of ZhongTeng ZT-010 Hexmesh Refractory is 1300 square meters per month.
