Inconel 625 Alloy Sheet N06625 Corrosion Resistant Metal Plate
Inconel 625 Alloy Sheet N06625 Corrosion Resistant Metal Plate
Inconel 625 Alloy Sheet N06625 Corrosion Resistant Metal Plate
Inconel 625 Alloy Sheet N06625 Corrosion Resistant Metal Plate
Inconel 625 Alloy Sheet N06625 Corrosion Resistant Metal Plate
Inconel 625 Alloy Sheet N06625 Corrosion Resistant Metal Plate
Specifications
Brand Name :
TSING SHAN
Model Number :
Inconel 625
Certification :
ISO SGS MTC
Place of Origin :
China
MOQ :
100KGS
Price :
22-65 USD/KG
Payment Terms :
L/C, T/T
Supply Ability :
50000KGS
Delivery Time :
7 Days
Packaging Details :
Export Packing
Specific Heat Capacity :
0.431 J/g-°C
Coefficient Of Expansion :
5.0 × 10⁻⁶ /°C (30–400°C~)
Alloys :
Inconel Alloys
Machinability :
Difficult
Special Use :
Compressor disks,machine manufacturing
Applications :
Aerospace, Chemical Processing, Nuclear Reactors, Gas Turbines, Heat Exchangers, Marine Engineering
Delivery State :
Sosoloid
Yield Strengt :
310 MPa
Hardness :
Rockwell C 30
Spray Process :
Flame, Arc, Plasma
Hs Code :
7507120000
Brinell Hardness Hb :
≤290
Tensile Strength Rm :
600 N/mm²
Application :
Industrial,Construction,Building
Description

Inconel Alloy 625 Sheet Corrosion Resistant Inconel 625 N06625/2.4856 /0Cr20Ni65Mo10bN4 /NS336 Metal Plate

Material
Monel/Inconel/Hastelloy/Duplex Steel/PH Steel/Nickel Alloy
Shape
Round,Forging,Ring,Coil,Flange,Disc,Foil,Spherical,Ribbon,Square,Bar,Pipe,Sheet
Grade
Duplex: 2205(UNS S31803/S32205),2507(UNS S32750),UNS S32760(Zeron 100),2304,904L
Others:253Ma,254SMo,654SMo,F50(UNSS32100)F60,F61,F65,1J22,N4,N6 etc
Alloy : Alloy 20/28/31
Hastelloy:HastelloyB/ -2/B-3/C22/C-4/S/ C276/C-2000/G-35/G-30/X/N/g
Hastelloy B / UNS N10001,Hastelloy B-2 / UNS N10665 / DIN W. Nr. 2.4617,Hastelloy C,
Hastelloy C-4 / UNS N06455 / DIN W. Nr. 2.4610,Hastelloy C-22 / UNS N06022 / DIN W. Nr. 2.4602,
Hastelloy C-276 / UNS N10276 / DIN W. Nr. 2.4819,Hastelloy X / UNS N06002 / DIN W. Nr. 2.4665
Haynes: Haynes 230/556/188
Inconel 600/601/602CA/617/625/713/718/738/X-750,Carpenter 20
Inconel 718 / UNS N07718 / DIN W. Nr. 2.4668,Inconel 601 / UNS N06601 / DIN W. Nr. 2.4851,
Inconel 625 / UNS N06625 / DIN W. Nr. 2.4856,Inconel 725 / UNS N07725,Inconel X-750 / UNS N07750 / DIN W. Nr. 2.4669,Inconel 600 /
UNS N06600 / DIN W. Nr. 2.4816
Incoloy: Incoloy 800/800H/800HT/825/925/926;
GH: GH2132,GH3030,GH3039,GH3128,GH4180,GH3044
Monel: Monel 400/K500/R405
Nitronic: Nitronic 40/50/60;
Nimonic: Nimonic 75/80A/90/A263 ;
Specification
Wire: 0.01-10mm
Strip: 0.05*5.0-5.0*250mm
Bar: φ4-50mm;Length 2000-5000mm
Pipe: φ6-273mm;δ1-30mm;Length 1000-8000mm
Sheet: δ 0.8-36mm;Width 650-2000mm;Length 800-4500mm

Product Paramenters

Steel grade Inconel 600 Inconel 601 Inconel 625 Inconel 718 Inconel 725 Inconel X-750
Corresponding brand N06600/2.4816
/1Cr15Ni75Fe8
/NS312/CY40		 N06601/2.4851
/1Cr23Ni60Fe13AI
/NS313		 N06625/2.4856
/0Cr20Ni65Mo10bN4
/NS336

N07718/2.4668

/GH4169

 N07725

N07750
/2.4669/

GH4145

Chemical composition%
C≤ 0.150 0.100 0.100 0.080 0.030 0.080
Mn≤ 1.00 1.00 0.50 0.35 0.35 1.00
P≤ / / 0.015 0.015 0.015 /
S≤ 0.015 0.015 0.015 0.015 0.010 0.010
Si≤ 0.50 0.50 0.50 0.35 0.20 0.50
Cr≤ 14.0-17.0 21.0-25.0 20.0-23.0 17.0-21.0 19.0-22.5 14.0-17.0
Ni≤ ≥72.0 58.0-63.0 ≥58.0 55.0-59.0 55.0-59.0 ≥70
Mo / / 8.0-10.0 2.8-3.3 7.0-9.5 /
Cu ≤0.50 ≤1.50 / ≤0.30 / ≤0.50
N / / / / /
Nb / / 3.15-4.15 4.75-5.50 2.75-4.00 0.70-1.20
other Fe:6.0-10.0 Al:1.0-1.7

Co:≤1.0Ai:≤0.40

Tr:0.40Fe:≤5.0

 AI:0.20-0.80Ti:0.65-1.15B≤0.006 Tr:1.0-1.7AI≤0.35

Co:≤1.0

AI:0.4-1.0

Tr:0.25-2.75

Fe:5.0-9.0

Inconel 625 Alloy Sheet N06625 Corrosion Resistant Metal Plate

Inconel 625 Alloy Sheet N06625 Corrosion Resistant Metal PlateInconel 625 Alloy Sheet N06625 Corrosion Resistant Metal Plate

Common Applications of Alloy 625

  • Structural members in hot sections of gas turbines such as discs, thrust reversers, and ducts
  • Aircraft structures
  • Rocket engines
  • Nuclear reactors
  • Heat treat fixtures
  • Cryogenic vessels: springs,and fasteners
  • Wire formulation with heat temper used in springs at elevated temperature

Q1:What product information must I provide before making a purchase?
Please provide the grade, width, thickness, and surface treatment requirements, as well as the quantities you require.

Q2:What shipping ports are there?
We normally ship from Shanghai, Tianjin, Qingdao, and Ningbo ports

Q3:What are your payment terms?
30% T/T in advance and 70% balance before shipment or based on BL copy or LC at sight.

Q4:What about product pricing information?
Prices vary due to changes in raw material prices on a regular basis.

Q5:Is it possible to send samples?
Of course, we offer free samples and express shipping to customers all over the world.

Q6:Do you offer a service for customized products?
Yes, we can produce according to your specifications and drawings.

Q7:Can you assist me in importing steel products for the first time?
Yes, we have shipping agent who will arrange the shipment with you.

Q8. What is your delivery time?
Within 7 working days after receiving your balance payment.
