Cold Rolled SS 316L Stainless Steel Sheet with Bright Surface and Superior Corrosion Resistance
Cold Rolled SS 316L Stainless Steel Sheet with Bright Surface and Superior Corrosion Resistance
Cold Rolled SS 316L Stainless Steel Sheet with Bright Surface and Superior Corrosion Resistance
Cold Rolled SS 316L Stainless Steel Sheet with Bright Surface and Superior Corrosion Resistance
Cold Rolled SS 316L Stainless Steel Sheet with Bright Surface and Superior Corrosion Resistance
Cold Rolled SS 316L Stainless Steel Sheet with Bright Surface and Superior Corrosion Resistance
Cold Rolled SS 316L Stainless Steel Sheet with Bright Surface and Superior Corrosion Resistance
Cold Rolled SS 316L Stainless Steel Sheet with Bright Surface and Superior Corrosion Resistance
Cold Rolled SS 316L Stainless Steel Sheet with Bright Surface and Superior Corrosion Resistance
Cold Rolled SS 316L Stainless Steel Sheet with Bright Surface and Superior Corrosion Resistance
Specifications
Certification :
ISO, AISI, ASTM
MOQ :
50
Price :
1.65
Model NO. :
316l
Shape :
Flat
Technique :
Cold Rolled
Surface Treatment :
Bright
Cr Content :
16%
Ni Content :
10%
Mo Content :
2%
Specification :
1220*2440, 1500*3000, 1500*6000, 2000*6000mm
Production Capacity :
50000kgs
Thickness Range :
0.1 to 100 mm
Width Range :
10-2500mm
Length Options :
2m, 2.44m, 3m, or as required
Hardness Options :
Soft, Hard, Half Hard, Quarter Hard, Spring Hard
UTS :
91 ksi (627 MPa)
0.2% YS :
42 ksi (290 MPa)
Description
Type 316 Austenitic Stainless Steel Sheets Overview
316/316L Stainless Steel Sheet is a premium grade stainless steel where superior corrosion resistance is essential. This material is widely used in marine environments, highly acidic conditions, underwater equipment, surgical tools, and food/pharmaceutical applications. The addition of molybdenum enhances corrosion resistance compared to the more economical 304 grade.
Available Product Forms
  • Sheet and Plate
  • Coil and Strip
  • Wire and Bar
  • Pipe and Tube
  • Profile Shapes (Round, Flat, Square, Hexagonal)
Specifications and Standards
Specifications: AMS 5507, AMS 5524, AMS 5648, AMS 5653, ASME SA 240, ASME SA 312, ASME SA 479, ASTM A 240, ASTM A 276, ASTM A 312, ASTM A 479, EN 1.4404
Product Type: SS 316 Sheet, SS 316 Plate
Material Grade: ASTM A240 / ASME SA240 Grade 316
Standards: ASTM A 480, ASTM A 959, ASME IID, EN ISO 9445, EN ISO 18286, EN 10088-1, ISO 15510
Available Sizes and Dimensions
Cold Rolled Sheet: 0.5-6.4 mm thickness
Hot Rolled Sheet: 3.0-10.0 mm thickness
Thickness Range: 0.1 to 100 mm
Width Range: 10-2500 mm
Length Options: 2m, 2.44m, 3m, or custom lengths
Surface Finishes
2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN, No.1 finish hot rolled, 1D, No.4, BA, 8K, satin, hairline, brush, mirror, and specialized coatings.
Applications
  • Food Processing Equipment
  • Marine Applications
  • Surgical Instruments
  • Firearms Production
  • Pulp & Paper Industry
  • Chemical Process Vessels
  • Pharmaceutical Equipment
Chemical Composition
Element Type 316 (wt %) Type 316L (wt %)
Carbon (C) 0.08 max. 0.03 max.
Manganese (Mn) 2.00 max. 2.00 max.
Phosphorus (P) 0.045 max. 0.045 max.
Sulfur (S) 0.030 max. 0.03 max.
Silicon (Si) 0.75 max. 0.75 max.
Chromium (Cr) 16.00 - 18.00 16.00 - 18.00
Nickel (Ni) 10.00 - 14.00 10.00 - 14.00
Molybdenum (Mo) 2.00 - 3.00 2.00 - 3.00
Nitrogen (N) 0.10 max. 0.10 max.
Iron (Fe) Balance Balance
Mechanical Properties
Room Temperature Properties
UTS ksi (MPa) 0.2% YS ksi (MPa) Elongation % in 2" Rockwell Hardness
91 (627) 42 (290) 55 B79
Elevated Temperature Properties
Temperature °F (°C) UTS ksi (MPa) 0.2% YS ksi (MPa) Elongation % in 2"
400 (204) 81 (558) 35 (241) 51
600 (316) 78 (538) 31 (214) 48
800 (427) 76 (524) 28 (190) 47
1000 (538) 70 (483) 24 (165) 44
1200 (649) 57 (393) 21 (145) 40
1400 (760) 35 (241) 18 (124) 37
1600 (871) 24 (165) 16 (110) 44
Technical Characteristics
Corrosion Resistance
Types 316 and 316L stainless steels provide enhanced chloride corrosion resistance compared to Type 304 due to molybdenum content. Suitable for marine atmospheres where pitting corrosion is a concern. Excellent resistance to chemicals in paper, petroleum, food, and dairy industries. Effective in sulfuric acid environments below 5% concentration up to 150°F (60°C).
Heat Treatment
Annealing: Heat to 1900-2100°F (1038-1149°C), then rapidly quench.
Formability and Weldability
Excellent ductility in annealed condition for roll forming, deep drawing, and bending. Weldable using common fusion and resistance techniques with proper procedures to avoid hot cracking. Type 316L eliminates harmful carbide precipitation during welding.
Product Images
Cold Rolled SS 316L Stainless Steel Sheet with Bright Surface and Superior Corrosion Resistance Cold Rolled SS 316L Stainless Steel Sheet with Bright Surface and Superior Corrosion Resistance Cold Rolled SS 316L Stainless Steel Sheet with Bright Surface and Superior Corrosion Resistance Cold Rolled SS 316L Stainless Steel Sheet with Bright Surface and Superior Corrosion Resistance Cold Rolled SS 316L Stainless Steel Sheet with Bright Surface and Superior Corrosion Resistance Cold Rolled SS 316L Stainless Steel Sheet with Bright Surface and Superior Corrosion Resistance
