EN 1.4510 DIN SUS439m AISI 439 Cold Rolled Stainless Steel Sheet with Ferritic Structure and Intergranular Corrosion Resistance
EN 1.4510 DIN SUS439m AISI 439 Cold Rolled Stainless Steel Sheet with Ferritic Structure and Intergranular Corrosion Resistance
EN 1.4510 DIN SUS439m AISI 439 Cold Rolled Stainless Steel Sheet with Ferritic Structure and Intergranular Corrosion Resistance
EN 1.4510 DIN SUS439m AISI 439 Cold Rolled Stainless Steel Sheet with Ferritic Structure and Intergranular Corrosion Resistance
EN 1.4510 DIN SUS439m AISI 439 Cold Rolled Stainless Steel Sheet with Ferritic Structure and Intergranular Corrosion Resistance
EN 1.4510 DIN SUS439m AISI 439 Cold Rolled Stainless Steel Sheet with Ferritic Structure and Intergranular Corrosion Resistance
EN 1.4510 DIN SUS439m AISI 439 Cold Rolled Stainless Steel Sheet with Ferritic Structure and Intergranular Corrosion Resistance
EN 1.4510 DIN SUS439m AISI 439 Cold Rolled Stainless Steel Sheet with Ferritic Structure and Intergranular Corrosion Resistance
EN 1.4510 DIN SUS439m AISI 439 Cold Rolled Stainless Steel Sheet with Ferritic Structure and Intergranular Corrosion Resistance
EN 1.4510 DIN SUS439m AISI 439 Cold Rolled Stainless Steel Sheet with Ferritic Structure and Intergranular Corrosion Resistance
Specifications
Certification :
AISI
MOQ :
100
Price :
1.55
Model NO. :
439
Shape :
Flat
Technique :
Cold Rolled
Surface Treatment :
Bright
Specification :
1220*2440, 1500*3000, 1500*6000, 2000*6000mm
Production Capacity :
500000kgs
Carbon Content :
0.070
Silicon Content :
1.00
Manganese Content :
1.00
Phosphorus Content :
0.040
Sulfur Content :
0.030
Chromium Content :
17.00~19.00
Titanium Content :
≥ 0.20+4(C+N)min - 0.50 max
Tensile Strength :
455
Yield Strength :
290
Description
EN 1.4510 DIN SUS439M AISI 439 Stainless Steel Sheet
439 stainless steel features a balanced composition that provides a completely ferritic structure at all temperatures, ensuring excellent ductility after welding and superior resistance to intergranular corrosion. Unlike similar ferritic stainless steels such as 430 and 434 alloys, which are susceptible to brittle martensite formation and intergranular corrosion sensitivity in the as-welded condition, 439 stainless steel maintains its properties without requiring post-welding annealing.
This alloy offers exceptional resistance to stress corrosion cracking, excellent weldability, high thermal conductivity, and low thermal expansion characteristics, making it an ideal choice for various demanding applications. The close match of thermal expansion coefficients between 439 stainless steel tubes and carbon steel shells in shell and tube heat exchangers may eliminate the need for expansion joints.
With its low cobalt content compared to Type 304 stainless steel, 439 stainless steel is particularly suitable for nuclear applications. It also provides excellent oxidation and corrosion resistance for automotive exhaust system components and residential furnace primary heat exchangers where application temperatures exceed the capabilities of 409 stainless steel.
Chemical Composition of Stainless Steel 439
Grade C Si Mn P S Cr Ti
439 0.070 1.00 1.00 0.040 0.030 17.00~19.00 ≥ 0.20+4(C+N)min - 0.50 max
Typical Annealed State Mechanical Properties
Tensile Strength (MPa) Yield Strength (MPa) Elongation (%) Hardness (HB)
455 290 34 78
Available Product Forms
  • Hot-rolled wide strip
  • Cold-rolled wide strip
  • Slit strip
  • Cut sheets
  • Precision strip
We stock 439 hot and cold rolled stainless steel sheet, plate, strip, and coil in various sizes and specifications to meet your manufacturing requirements.
