Specifications
Certification :
AISI, ASTM
MOQ :
50
Price :
12.55
Model Number :
Inconel 600
Shape :
Flat
Technique :
Hot Rolled
Surface Treatment :
Polished
Specification :
1220*2440, 1500*3000, 1500*6000, 2000*6000mm
Production Capacity :
500000kgs
Nickel Content :
72.0-76.0%
Chromium Content :
14.0-17.0%
Iron Content :
6.0-10.0%
Carbon Content :
Max 0.15%
Manganese Content :
Max 1.0%
Silicon Content :
Max 0.5%
Sulfur Content :
Max 0.015%
Ultimate Tensile :
760 MPa
Yield Strength :
275-585 MPa
Description
Inconel 600 (UNS N06600) Nickel-Chromium Alloy Plate
Chemical Composition: Ni 72.0%, Cr 15.5%, Fe 8.0%, Mn 1.0%, C 0.15%, Cu 0.5%, Si 0.5%, S 0.015%
High Performance Alloys stocks and produces Inconel 600 in bar, wire cuts, sheet, plate, strip, tube, and pipe forms.
Product Overview
Inconel 600 is a nickel-chromium alloy designed for use from cryogenic to elevated temperatures up to 2000°F (1093°C). The alloy offers excellent oxidation resistance at high temperatures and provides good resistance in carburizing and chloride-containing environments.
Key Characteristics
  • Resistant to a wide range of corrosive media with chromium providing better resistance under oxidizing conditions
  • Virtually immune to chlorine ion stress corrosion cracking
  • Demonstrates adequate resistance to organic acids including acetic, formic, and stearic acids
  • Excellent resistance to dry gases such as chlorine or hydrogen chloride up to 550°C
  • Good resistance to scaling and high strength at elevated temperatures in annealed and solution annealed conditions
  • Resists ammonia-bearing atmospheres, nitrogen, and carburizing gases
  • Non-magnetic with excellent mechanical properties and good workability
  • Readily weldable with cold forming characteristics similar to chromium-nickel stainless steels
Applications
  • Thermocouple sheaths
  • Ethylene dichloride (EDC) cracking tubes
  • Conversion of uranium dioxide to tetrafluoride in contact with hydrofluoric acid
  • Production of caustic alkalis, particularly with sulfur compounds
  • Reactor vessels and heat exchanger tubing in vinyl chloride production
  • Process equipment for chlorinated and fluorinated hydrocarbons
  • Nuclear reactor components including control rod guide tubes and steam generator baffle plates
  • Furnace retort seals, fans, fixtures, roller hearths, and radiant tubes
Chemical Requirements
Element Min (%) Max (%)
Ni 72.0
C 0.15
Mn 1.0
Cr 14.0 17.0
S 0.015
Si 0.5
Fe 6.0 10.0
Mechanical Property Requirements
Cold Worked/As Worked
Property Min (KSI) Min (MPa) Elongation (%)
Ultimate Tensile 110 760 10
Yield Strength (0.2% OS) 85 585
Hot Worked/As Worked
Property Min (KSI) Min (MPa) Elongation (%)
Ultimate Tensile 90 620 25
Yield Strength (0.2% OS) 40 275
Forging quality is furnished to chemical requirements and surface inspection only. No mechanical properties required.
Specifications
Form Standard
Metal Type UNS N06600
Bar ASTM B166 AMS 5665 Din 17752
Sheet ASTM B168 AMS 5540 Din 17750
Plate ASTM B168 AMS 5540 Din 17750
Tube ASTM B167
Pipe ASTM B167
Fitting ASTM B366
Forging ASTM B564 Din 17754
Weld Wire FM 82/ ERNiCr-3
Weld Electrode FM 182/ ENiCrFe-3
Din 2.4816
Machining Data
Carbide tools are suggested for rates better than 50% of Type 304.
Machining Type Suggested Starting Rates
Single Point Turning Roughing - 0.15" depth, 0.015"/rev feed - 175 SFM
Finishing - 0.025" depth, 0.007"/rev feed - 200 SFM
Drilling 1/4" Dia hole - 0.004"/rev feed - 60 SFM
1/2" Dia hole - 0.007"/rev feed - 60 SFM
3/4" Dia hole - 0.010"/rev feed - 60 SFM
Reaming Feed - same as drilling - 100 SFM
Side and Slot Milling Roughing - 0.25" depth - 0.007"/tooth feed - 125 SFM
Finishing - 0.050" depth - 0.009"/tooth feed - 140 SFM
These rates are for carbide tools: Type C-2 for roughing, drilling and reaming; Type C-3 for finishing.
INCONEL® is a registered trademark of Special Metals Corporation.
