DIN1.4510 SUS439 Stainless Steel Sheet 2D Surface 0.5-3mm Used For Automotive Systems
DIN1.4510 SUS439 Stainless Steel Sheet 2D Surface 0.5-3mm Used For Automotive Systems
DIN1.4510 SUS439 Stainless Steel Sheet 2D Surface 0.5-3mm Used For Automotive Systems
DIN1.4510 SUS439 Stainless Steel Sheet 2D Surface 0.5-3mm Used For Automotive Systems
DIN1.4510 SUS439 Stainless Steel Sheet 2D Surface 0.5-3mm Used For Automotive Systems
DIN1.4510 SUS439 Stainless Steel Sheet 2D Surface 0.5-3mm Used For Automotive Systems
Specifications
Brand Name :
BAOSTEEL
Model Number :
439
Place of Origin :
China
MOQ :
1 t
Price :
Negotiation
Supply Ability :
500t
Delivery Time :
15 work days
Packaging Details :
Seaworthy Package
Certification :
ASTM,AISI,JIS,SUS,DIN,EN
Payment Terms :
L/C, T/T, Western Union
Name :
439 stainless steel sheets
Application :
Construction,Decoration,Elevator/Kitchen/Interior
Grade :
400 Series,439
Thickness :
0.5-3.0mm or customize
Technique :
Cold Rolled&Hot Rolled
Price term :
CFR,FOB,EXW
Sample :
Can be offered
Package :
Standard Seaworthy Package
Description

DIN1.4510 SUS439 Stainless Steel Sheet 2D Surface 0.5-3mm Used For Automotive Systems

ype 439 (UNS S43035) in Coil Form

Description
Type 439 is an 18% chromium, titanium stabilized ferritic stainless steel with corrosion resistance similar to that of 304/304L stainless steel. This grade may be used in the annealed, cold formed or as-welded condition in applications where other stainless steels such as Type 304/304L and Type 430 are used. Type 439 has good weldability due to titanium stabilization and has excellent resistance to stress corrosion cracking. Type 439 outperforms Type 409 in both oxidation and corrosion resistance and typical applications include tubular manifolds and exhaust system components.

Chemical Composition
Chemical Composition (wt%) limits as specified in ASTM A240 and ASME SA240*

Element 439
Carbon 0.030
Chromium 17.0-19.0
Nickel 0.50
Manganese 1.00
Silicon 1.00
Nitrogen 0.030
Phosphorus 0.040
Sulfur 0.030
Aluminum 0.15
Titanium 0.20 +4(C+N) min
1.10 max
* Maximum, unless range is indicated

Mechanical Properties
Mechanical property requirements for annealed product as specified in ASTM A240 and ASME SA240

Property 439
Yield Strength, min. (ksi) 30
Tensile Strength, min. (ksi) 60
Elongation, min. (%) 22
Hardness, max. (Rb) 89

Physical Properties
Physical properties for Type 439 stainless steel

Property 439
Density, lb/in3 0.278
Modulus of Elasticity, psi 29.0 x 106
Coefficient of Thermal Expansion, 68-212˚F, /˚F 5.6 x 10-6
Thermal Conductivity, Btu/ft hr ˚F 14.0
Specific Heat, Btu/lb ˚F 0.11
Electrical Resistivity, Microohm-in 24.8
