2W 4W 5050 5054 SMD LED RGBW 4 In 1 High Brightness LED Chip for Stage and Decorative Lighting
2W 4W 5050 5054 SMD LED RGBW 4 In 1 High Brightness LED Chip for Stage and Decorative Lighting
2W 4W 5050 5054 SMD LED RGBW 4 In 1 High Brightness LED Chip for Stage and Decorative Lighting
2W 4W 5050 5054 SMD LED RGBW 4 In 1 High Brightness LED Chip for Stage and Decorative Lighting
2W 4W 5050 5054 SMD LED RGBW 4 In 1 High Brightness LED Chip for Stage and Decorative Lighting
2W 4W 5050 5054 SMD LED RGBW 4 In 1 High Brightness LED Chip for Stage and Decorative Lighting
2W 4W 5050 5054 SMD LED RGBW 4 In 1 High Brightness LED Chip for Stage and Decorative Lighting
2W 4W 5050 5054 SMD LED RGBW 4 In 1 High Brightness LED Chip for Stage and Decorative Lighting
Specifications
Brand Name :
HuanYu Dream
Model Number :
HY-5054RGBW
Certification :
RoHS
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T,Paypal,Ali Pay
Supply Ability :
200KKpcs/Month
Delivery Time :
7-9 Work Days
Packaging Details :
1000pcs/Reel
Type :
5054RGBW
Power :
2W
Voltage :
2.0-2.4V/3.0-3.6V
Current :
150mA*4
Feature :
RGBW 4 colors in one
Availiable Power :
0.2W, 0.8W, 2W, 4W
Description
2W 4W Multi Color SMD LED Chip SMD 5050 RGBW 4 In 1 High Brightness
Product Overview

2W 4W 5050 SMD LED Chip RGBW 4-Chip-Built-In RGBW 5050 SMD 4 In 1 SMD 5050 RGBCW LED Light


Product Overview

✅ Lower Cost, High Cost-Effectiveness
The price of a single 5050 LED chip is significantly lower than that of 10W/18W imitation lumen LED chips, reducing the overall material cost of the lamp by 30%~50%.

Suitable for budget-conscious scenarios such as economical stage lights, bar ambient lighting, and wedding color-changing lights.

✅ More Uniform Light Efficiency, No Obvious Light Spots

The small size and high density of 5050 LED chips allow for dense arrangement on the light panel, resulting in softer and more uniform light emission, avoiding the "grainy" light spots common with imitation lumen LED chips.

Ideal for soft PAR lights, wall washer lights, and ambient color-changing lights, providing a more natural transition in lighting for people/scenes.

✅ Lower Heat Dissipation Pressure, More Flexible Structural Design
With a single chip power of only 0.2W~0.5W, the total heat generated by the entire lamp is far lower than high-power LED chip solutions, allowing for a simplified heat dissipation structure and a thinner, lighter lamp body.

Easy to make ultra-thin flat PAR lights, battery-powered wireless lights, and portable stage lights, suitable for mobile performances and small events.

✅ High control precision and delicate color transitions

Supports independent dimming for individual LEDs (DMX512/SPI), enabling pixel-level control for smoother effects such as gradients, running lights, and dynamic visuals.

Suitable for LED matrix lights, background walls, and interactive stage installations, offering enhanced visual impact.

Technical Specifications

5054 SMD LED RGBW 4in1, available in 0.2W, 0.8W, 2W, 4W power ratings. Features 4-channel separate control with excellent light and color mixing capabilities. Delivers high brightness and superior light efficiency.

  • 1W monochrome, 4W total 4-channel separate control
  • Superior light and color mixing performance
  • High brightness and high light efficiency
  • Compact, convenient, and flexible design
2W 4W 5050 5054 SMD LED RGBW 4 In 1 High Brightness LED Chip for Stage and Decorative Lighting
2W Model Specifications
Model No. RGBW SMD 5054 LED HY-5054W40-2W
LED Package 5.0mm*5.4mm
Data Color Red | Green | Blue | White
Wave Length 625nm-635nm | 520nm-530nm | 465nm-475nm | 2000-7000K
Flux 20-25LM | 33-38LM | 10-12LM | 58-63LM
Typical Forward Voltage 2.0-2.4V | 3.0-3.4V | 3.0-3.4V | 3.0-3.4V
DC Forward Current 150mA*4
Typical Power Dissipation 2W
4W Model Specifications
Model No. RGBW SMD 5054 LED HY-5054W40-4W
LED Package 5.0mm*5.4mm
Data Color Red | Green | Blue | White
Wave Length 625nm-635nm | 520nm-530nm | 465nm-475nm | 4000-7000K
Flux 38-43LM | 75-80LM | 17-19LM | 120-130LM
Typical Forward Voltage 2.0-2.4V | 3.0-3.4V | 3.0-3.4V | 3.0-3.4V
DC Forward Current 300mA*4
Typical Power Dissipation 4W
Emitting Color RGB | W
Viewing Angle 120°
Operating Temperature -40℃～+100℃
Storage Temperature -40℃～+100℃
Available in a broad range of CCT (2600-7000K). Contact us for specific requirements and wavelength customization.
Package Dimensions
2W 4W 5050 5054 SMD LED RGBW 4 In 1 High Brightness LED Chip for Stage and Decorative Lighting
Applications
  • High Power LED Lamp
  • Down light, wall lamp, garden light
  • Stage lighting
  • Spot lighting, ceiling light
  • Decorative lighting, show lighting
  • Landscape lighting, lighting engineering
2W 4W 5050 5054 SMD LED RGBW 4 In 1 High Brightness LED Chip for Stage and Decorative Lighting
2W 4W 5050 5054 SMD LED RGBW 4 In 1 High Brightness LED Chip for Stage and Decorative Lighting
2W 4W 5050 5054 SMD LED RGBW 4 In 1 High Brightness LED Chip for Stage and Decorative Lighting
Frequently Asked Questions
Q1: What is the MOQ?
A: Our MOQ is 1 piece. We can do OEM/ODM if you need.
Q2: How to process the order?
A: 1. Let us know your requirement.
2. We make a quotation and provide our advice
3. We will make a PI after you confirm the quotation.
4. You make the payment after checking the details.
5. We arrange the delivery as soon as possible.
Q3: How can I order samples?
A: We can send you samples if you need. You should pay the sample fee and freight. The sample fee will be refunded after bulk order.
Q4: How many days do you need for preparing order?
A: We need 5-7 days for normal order. Custom product cycle is 10-15 days.
Q5: How many years of warranty of your products?
A: We offer 3 year warranty time. If there is any problem (no man-made damage) during the warranty time, please contact us and we will change or repair them for you for free.
