Dual Color 3030 SMD LED Chip 660nm 850nm 730nm 1072nm Two Colors Spectrum Customization Available 1W For Therapy hat cap
Dual Color 3030 SMD LED Chip 660nm 850nm 730nm 1072nm Two Colors Spectrum Customization Available 1W For Therapy hat cap
Dual Color 3030 SMD LED Chip 660nm 850nm 730nm 1072nm Two Colors Spectrum Customization Available 1W For Therapy hat cap
Dual Color 3030 SMD LED Chip 660nm 850nm 730nm 1072nm Two Colors Spectrum Customization Available 1W For Therapy hat cap
Dual Color 3030 SMD LED Chip 660nm 850nm 730nm 1072nm Two Colors Spectrum Customization Available 1W For Therapy hat cap
Dual Color 3030 SMD LED Chip 660nm 850nm 730nm 1072nm Two Colors Spectrum Customization Available 1W For Therapy hat cap
Specifications
Brand Name :
HuanYu Dream
Model Number :
3030-bi color
Certification :
RoHS
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T,Paypal,Ali Pay
Supply Ability :
500000pcs/Day
Delivery Time :
7-9 Work Days
Packaging Details :
5000pcs/Reel
LED Type :
3030 Smd Led
Color(CCT) :
660nm+850nm
Voltage :
3.0-3.2V
Power :
single channel 0.5 watts
CRI :
80
SUBSTRATE :
PCT
Warranty :
3 Years
Feature :
2 colors
Description
Dual Color 3030 SMD LED Chip 660nm 850nm 730nm 1072nm Two Colors Spectrum Customization Available 1W For Therapy hat cap
Product Description

Dual Color 2835 SMD LED Chip with Red 650nm 660nm add Infrared Red 730nm 850nm 940nm 1072nm Full Spectrum Customization Available

Key Features
  • Power: 1W(3V*150mA*2) tunable color
  • Low thermal resistance
  • Super Long life >50000hrs
  • Compact structure, smaller size can achieve higher power
  • White colors available in (2700K-25000K), Color mixing with high CRI
  • Bright Colors and true appearance for Therapy Light Mask Belt Hat
Dual Color 3030 SMD LED Chip 660nm 850nm 730nm 1072nm Two Colors Spectrum Customization Available 1W For Therapy hat cap
Specifications
Electronic power 0.5W*2
Color temperature 660nm+850nm (450nm 520nm 850nm 730nm 1072nm are available)
CRI 80
VF 3.0-3.2V
IF 150mA*2
Lumen 75-80LM/3-5LM
WHOLE SIZE 3.0*3.0mm
CHIP Sanan/Epistar
VIEW ANGLE 120°
Warranty 3 years
Leading time 7-10days
Absolute Maximum Ratings at Ta=25℃
Dual Color 3030 SMD LED Chip 660nm 850nm 730nm 1072nm Two Colors Spectrum Customization Available 1W For Therapy hat cap
Dimensions (Tolerance:+/-0.1, Unit:mm)
Dual Color 3030 SMD LED Chip 660nm 850nm 730nm 1072nm Two Colors Spectrum Customization Available 1W For Therapy hat cap
Applications
  • Therapy Light
  • Indoor lighting: Fluorescent lamp, tube
  • Commercial illumination and displays: Advertising words, light box
  • Light strip
  • LCD Back lighting
  • Other illumination and displays
Dual Color 3030 SMD LED Chip 660nm 850nm 730nm 1072nm Two Colors Spectrum Customization Available 1W For Therapy hat cap
Detailed Application Scenarios
I. Home Lighting and Atmosphere
1. Main Bedroom Lighting and Sleep Aid

Utilizes dual-color SMD light source: Warm White (2700K-3000K) + Red Light (620-660nm). Warm white for daily lighting needs, red light mode for sleep-inducing atmosphere.

2. Living Room Ambiance and Function Switching

Dual-color SMD (cool white + warm yellow) for daytime brightness and nighttime cozy atmosphere.

II. Commercial Display and Decoration
1. Store Windows and Product Displays

Warm white + cool white combination for clothing stores, white light + violet light for jewelry/cosmetics.

III. Medical and Nursing Scenarios
1. Skin Care and Physical Therapy

Red light (660nm) + blue light (415nm) for skin treatment and acne improvement.

IV. Industrial and Indicator Scenarios
1. Device Status Indicator

Dual-color "red (fault) + green (normal)" for equipment control panels.

V. Consumer Electronics and Portable Devices
1. Mobile Phone/Tablet Fill Light

Warm white for portraits, cool white for scenery with color temperature adjustment.

About Us
Dual Color 3030 SMD LED Chip 660nm 850nm 730nm 1072nm Two Colors Spectrum Customization Available 1W For Therapy hat cap
FAQ
Q1. How to proceed an order for led light?
A: Firstly let us know your requirements or application. Secondly We quote according to your requirements or our suggestions. Thirdly customer confirms the samples and places order.
Q2. What about the lead time?
A: Sample needs 1-3 days, mass production time needs 3-7 days according to the order quantity.
Q3. Do you have any MOQ limit for led light order?
A: MOQ is 100pcs for each model.
Q4. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q5. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 2-5 days to arrive. Airline and sea shipping also optional.
Q6: How to deal with the faulty?
A: Our products have defective rate less than 0.2%. During the guarantee period, we will send new replacements.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 3 years warranty to our products.
