20ft Containerized Battery Storage System 860kWh 400kW Industrial
20ft Containerized Battery Storage System 860kWh 400kW Industrial
20ft Containerized Battery Storage System 860kWh 400kW Industrial
20ft Containerized Battery Storage System 860kWh 400kW Industrial
20ft Containerized Battery Storage System 860kWh 400kW Industrial
20ft Containerized Battery Storage System 860kWh 400kW Industrial
20ft Containerized Battery Storage System 860kWh 400kW Industrial
20ft Containerized Battery Storage System 860kWh 400kW Industrial
20ft Containerized Battery Storage System 860kWh 400kW Industrial
20ft Containerized Battery Storage System 860kWh 400kW Industrial
Specifications
Brand Name :
1stess
Model Number :
EnerCube
Certification :
1
Place of Origin :
China
MOQ :
1
Price :
negotiable
Payment Terms :
L/C,T/T
Supply Ability :
10 containers per month
Delivery Time :
60-90 days
Packaging Details :
container
Monitoring System :
Remote Monitoring And Control
Voltage Range :
400-800V
Container Size :
20ft
Warranty :
5 Years
Application :
Power Grid Stabilization And Peak Shaving
Battery Capacity :
Negotiable
Description

Product Features:

Modular design


All-in-One design


Supports AC and Dc coupling


Standard 20HQ container


Classification society certification


7*24 hours monitoring


Online assisted O&M


Product Parameters:

Type
P400C860
P500C1075
P600C1290
P700C1505
P800C1720
DC side parameters
Cell type &capacity
LiFePO₄-280Ah
Battery module type
1P20S
System configuration
4*1P240S
5*1P240S
6*1P240S
7*1P240S
8*1P240S
Capacity(BOL)
860kWh
1075kWh
1290kWh
1505kWh
1720kWh
AC side parameters
Grid type
3P4W+PE
Rated output power
400kW
500kW
600kW
700kW
800kW
Rated voltage
AC400V
Rated frequency
50/60(±5)Hz
Maximum output current
577A
722A
866A
1010A
1155A
Harmonics
<3%(@rated power)
Overload capacity
110%,10mins;120%,60s
General parameters
Isolation transformer
No
Protection level
Outdoor installation (Battery cabinet:IP55,Electrical room:IP34)
Container anti-corrosion grade
C3
Operation temperature*
-20℃~50℃
Relative humidity
0~95%(non-condensing)
Permissible altitude**
<2000m
Cooling method
Battery cabinet:HVAC,Electrical room:forced air cooling
Fire fighting system
FAS &FM200/Novec1230
Noise emission
≤75dB
Dimension (W*D*H)
20HQ container (6058mm*2438mm*2896mm)
Maximum weight
24500kg
Communication interface
Ethernet
Communication protocol
Modbus TCP/IP
Warranty
5 years (can be extended to 10 years)Warranty

Certification
System:UN3536,LVD,EMC,RoHS Cell:IEC62619,UL1973,UL9540A PACK:UN38.3
PCS:G99,EN50549,AS4777.2,VDE4105




20ft Containerized Battery Storage System 860kWh 400kW Industrial20ft Containerized Battery Storage System 860kWh 400kW Industrial20ft Containerized Battery Storage System 860kWh 400kW Industrial20ft Containerized Battery Storage System 860kWh 400kW Industrial20ft Containerized Battery Storage System 860kWh 400kW Industrial

Product Overview:

EnerCube3.0 containerized Battery Energy Storage System adopts an All-in-Onemodular design, integrating the battery PACK, intelligent energy storage converter(PCS), power distribution unit (PDU), automatic fire extinguishing system (FFS), and temperature control system (TCS),intelligent monitoring system (IMS), etc.areintegrated into one, and the 20HQ standard container design is adopted, which saves application space and facilitates transportation, hoisting, installation and maintenance.Plug-and-play design greatly reduces on-site construction time and costs.


EnerCube3.0 containerized Battery Energy Storage System supports integrated transportation with batteries, with single clusters in cabinets, thermal isolation between clusters, and independent maintenance of each cluster. The air-condition er,FFS, and BMS are independent of each other. The clusters adopt an exclusive patent toprevent open flame leakage , combined with the self-developed operation andmaintenance platform, can quickly realize fault prediction and location.
