Specifications
Model Number :
EnerCube
Payment Terms :
L/C,T/T
Voltage Range :
400-800V
Application :
Power Grid Stabilization And Peak Shaving
Price :
negotiable
Container Size :
20ft
Supply Ability :
10 containers per month
Monitoring System :
Remote Monitoring And Control
Warranty :
5 Years
MOQ :
1
Delivery Time :
60-90 days
Battery Capacity :
Negotiable
Packaging Details :
container
Place of Origin :
China
Certification :
1
Brand Name :
1stess
Description
AC/DC Dual-Coupling Container Battery Storage System
All-in-one integrated energy storage solution featuring forced air cooling, HVAC temperature control, FM200 fire suppression, and ≤75dB noise operation in a standard 20HQ container.
Key Features
  • All-in-One Integration: Combines battery PACK, PCS, PDU, fire suppression, temperature control, and intelligent monitoring in a single container
  • Plug-and-Play Deployment: Modular design with battery-integrated transport reduces on-site construction time and cost
  • Independent Cluster Management: Single cluster per cabinet with thermal isolation between clusters for enhanced safety and maintenance
  • Smart Operation & Maintenance: Proprietary platform with patented anti-flame leakage technology for fault prediction and location
  • Wide Environmental Adaptability: Operating range -20℃ to 50℃, altitude up to 2000m (derated above)
  • International Certifications: System, cell, PACK, and PCS meet UN3536, UL1973, IEC62619, G99 standards
  • 24/7 Monitoring: Continuous online monitoring with round-the-clock remote O&M support
System Specifications
Modular Design Standard 20HQ container, flexible configuration
AC/DC Coupling Supports both AC and DC coupling
Protection Rating Battery cabinet IP55, electrical room IP34, outdoor installation
Anti-corrosion Grade C3
Cooling Method Battery cabinet: HVAC; Electrical room: forced air cooling
Fire Fighting System FAS + FM200/Novoc1230
Noise Emission ≤75dB
Communication Ethernet, Modbus TCP/IP
Performance Specifications
Energy Capacity Range: 860kWh - 1720kWh (BOL)
Rated Output Power: 400kW - 800kW
Rated Voltage: AC400V, 3P4W+PE
Frequency: 50/60Hz ±5%
Harmonic Distortion: <3% (@ rated power)
Overload Capacity: 110% for 10 min, 120% for 60 s
Warranty: 5 years (extendable to 10 years)
Technical Models Comparison
Type P400C860 P500C1075 P600C1290 P700C1505 P800C1720
DC Side Parameters
Cell type & capacity LiFePO₄-280Ah
Battery module type 1P20S
System configuration 4*1P240S 5*1P240S 6*1P240S 7*1P240S 8*1P240S
Capacity (BOL) 860kWh 1075kWh 1290kWh 1505kWh 1720kWh
AC Side Parameters
Grid type 3P4W+PE
Rated output power 400kW 500kW 600kW 700kW 800kW
Rated voltage AC400V
Rated frequency 50/60(±5)Hz
Maximum output current 577A 722A 866A 1010A 1155A
General Parameters
Isolation transformer: No
Protection level: Outdoor installation (Battery cabinet: IP55, Electrical room: IP34)
Container anti-corrosion grade: C3
Operation temperature: -20℃ to 50℃
Relative humidity: 0-95% (non-condensing)
Permissible altitude: <2000m
Cooling method: Battery cabinet: HVAC, Electrical room: forced air cooling
Fire fighting system: FAS & FM200/Novec1230
Noise emission: ≤75dB
Dimension (W*D*H): 20HQ container (6058mm * 2438mm * 2896mm)
Maximum weight: 24500kg
Communication interface: Ethernet
Communication protocol: Modbus TCP/IP
Certifications
System: UN3536, LVD, EMC, RoHS | Cell: IEC62619, UL1973, UL9540A | PACK: UN38.3 | PCS: G99, EN50549, AS4777.2, VDE4105
