Diaphragm Coating Machine For Production
Diaphragm Coating Machine For Production
Specifications
Description
Diaphragm Coating Machine For Production
Advanced diaphragm coating machine designed for lithium battery separator production with precision coating capabilities.
Technical Specifications
No. Parameter Specification
1 Process Adaptability Lithium battery separator coating
2 Coating Method Continuous coating
3 Rewind Volume Configuration Single-axis / Dual-axis manual roll exchange
4 Substrate Processing Preheat oven / Ironing roller (surface leveling)
5 Heating Method Electric heating / Steam heating / Oil heating
6 Oven Configuration Curved active over roller, length options
7 Mechanical Speed Coating speed + 10%
8 Coating Speed 50m/min, 80m/min, 100m/min (depending on model)
9 Coating Width 600mm, 900mm, 1200mm
10 Coating Thickness -
11 Thickness Accuracy ±0.5μm (when coating thickness is greater than 1μm)
Key Advantages
  • System control with easy operation and intuitive touch screen interface
  • Pendulum roller structure and closed-loop tension control system for low-tension operation
  • Preheating oven treatment for substrate problems and irregularities with equipment improvements
  • Fourth-generation closed joint research and production design for uniform scraping, easy cleaning and replacement
